PXM Lighting PX815-2 2 Channel DMX/Relay Interface
Overview
DMX/Relay Interface is a relay controlled by DMX-512 signal available in two versions: 2 or 3 channels. In the version with two channels, the possible output load is 16A per channel, while in the version with three channels up to 13A per channel.
PX815 is a device used to switch architectural illuminators or stage effects via DMX-512 signal.
The module includes relays that control the on / off outputs and has a built-in hysteresis system. The device is equipped with a DMX signal input and output. It is produced in a housing adapted for mounting on a 35mm DIN rail. The PX815 is designed to operate when connecting different phases to the control connectors. What is more, the device has been equipped with RDM protocol support.
Note! To update the software, download the file compatible with the device version and the processor used.
Specifications
| DMX IN/OUT channels | 512 |
| output channels | PX815-2: 2 PX815-3: 3 |
| outputs load capacity | PX815-2: max. 16 A, 240 V AC / channel PX815-3: max. 13 A, 240 V AC / channel |
| output connectors | screw terminal |
| power consumption without load | max. 2 W |
| RDM | YES |
| power supply | 12 – 24 V DC |
| weight | 0,2 kg |
| dimensions | width: 52mm (3 DIN rail modules) height: 90mm depth: 58mm |
