PXM Lighting PX786 Gate 4 DMX
Overview
Gate 4 DMX is a gate that converts Art-Net signals to four output DMX512 ports.
It is powered by 12 – 24V DC. The device is protected by a housing for a 35mm DIN rail protecting it against mechanical damage.
The device comes equipped with an Ethernet interface working in 10/100BaseTX protocol. The protocol version is Art-Net4 (compatible with Art-Net 1 – 4). DMX512 ports have optical and galvanic isolation.
On the housing there are six LEDs installed, four two-color ones responsible for data transfer on DMX ports and two one-color ones informing about the status of the Art-Net network connection.
The gate PX786 has a display and four buttons that allows to change the configuration: Art-Net, Ethernet and DMX settings (such as: Brake, MAB, MBF and the number of DMX channels transmitted).
Specifications
| DMX IN/OUT lines | 0/4 |
| DMX lines connectors | screw terminals |
| opticaly isolated DMX line | YES |
| power supply | 12 - 24 V DC |
| power consumption | max. 4 W |
| weight | 0.2 kg |
| dimensions | width: 105mm (6 DIN rail modules) height: 86mm depth: 60mm |
