Product Description
PXM Lighting PX716 Splitter DMX-RDM 3-PIN
Overview
This signal splitting device, or DMX-RDM splitter, allows for providing branches in extensive DMX-RDM installations. As connecting multiple, series-connected receivers to form a single chain can be difficult, provision has been made in the design of the splitter to create DMX-RDM line branches. Moreover, the PX716 will amplify and regenerate RDM-DMX signal, removing interference effects, as well as eliminating signal reflections on DMX-RDM lines.
The PX716 will split an input DMX-RDM signal into 4 independent branches. Galvanic isolation is provided between individual outputs themselves as well as from the input, and the outputs are adequately amplified, which ensures proper operation of the entire installation. The PX716 supports the RDM protocol. A maximum of four splitters can be connected in a cascading arrangement.
The PX716 splitter has a metal housing. Additional mounting kits are available for installing a single PX716 unit in a RACK system, two units side by side in a RACK system, or for suspending a PX716 from e.g. a grid structure.
The PX716 is designed to run from 230 V AC mains.
Specifications
| DMX IN/OUT lines | 1/4 |
| opticaly isolated DMX line | yes |
| isolation between input and outputs | >1000 V |
| DMX lines connectors | XLR 3-pin or 5-pin |
| power supply | 230 V AC |
| power consumption | 5 W |
| weight | 0,92 kg |
| dimensions | Width: 205 mm Height: 42,5 mm Depth: 155 mm |
