Product Description
PXM Lighting PX295 PxArt Splitter DMX
Overview
The DMX splitter allows you to create complex branching in DMX systems. With a large number of receivers combining them in series in a single chain can be tricky, so provides the ability to create branching path with a DMX splitter. If you use modules: T-Feed (PY636 and PY637) or X-feed (PY638) to create branching of tracks, PX295 splitter have to be used.
DMX signal splitter for GLOBALtrac control system. Using the PX295 you can divide input DMX-512 signal on three separate lines. In order to avoid the possibility of disruption in GLOBALtrac rail you should use splitter with more than 20 receivers (e.g. PX261) on a single DMX line. Individual track outputs are galvanic isolated from the input and each other, and accordingly strengthened to guarantee correct operation of the entire system.
Splitter is manufactured in a housing with adapter for quick mounting to the GLOBALtrac control rail and power supplying with 230V and DMX-512 control.
Specifications
| DMX IN/OUT channels | 512/512 |
| DMX IN/OUT lines | 1/3 |
| DMX lines connectors | terminal blocks |
| power supply | 230 V AC (directly from GLOBALtrac control) |
| weight | 0,5 kg |
| dimensions | width: 90 mm height: 50 mm overall height: 106 (with adapter) depth: 122 mm |
