Product Description
PXM Lighting PX227 0-10 Volt DMX Interface
Overview
Demultiplexer DMX-512 - DMX/0-10V interface
PX227 is designed to process the DMX-512 signal to control the analog 0 - 10 V. The device is manufactured in a housing designed for installation in electrical switchgear DIN rail T35.
In addition to simple decoding PX227 DMX allows you to select the characteristics of control and to program how the unit reacts to loss of DMX signal.
Individually programmable parameters allow to define independently for each channel DMX address of 1-512 - also multiple channels can be assigned to a single address.
ATTENTION! The layout of connectors in the device has changed from the serial number 21290007. Documentation version 2.0 and higher applies to devices after the change.
Specifications
| DMX IN/OUT channels | 512/512 |
| 0-10V IN/OUT ports | 0/8 |
| output connectors | screw terminals |
| 0-10V output load capacity | 30 mA / channel |
| power supply | 12-24V DC |
| maximum current consumption | 250 mA |
| dimensions | 70 (4 DIN rail modules)x 86 x 60 mm |
