Product Description
PreSonus HP60 6-Channel Headphone Mixing System
Overview
The HP60 solves a host of common headphone-monitoring problems. Each of its six headphone amps puts out 150 mW; if you can’t hear this headphone system, you’re stone deaf. Two global input channels and a Mix control let you adjust the click for each musician. Individual inputs let you send each musician a custom mix for “more me.”
- 6 screaming-loud (150 mW/channel) headphone amplifiers with level control
- 2 stereo input channels (A and B) with Mix control and Mute switch
- Talkback-microphone input with level control, Talk button, and footswitch jack
- 6 stereo ¼” external analog line inputs (1 per channel) for “more me”
- 1 balanced XLR input for external dynamic talkback microphone
Specifications
| Form Factor | Rackmount |
| Number of Headphone Channels | 6-Channel |
| Headphone Output Power | 150 mW RMS per Side into 60 Ohms (Max) |
| Display | None |
Connectivity
| Analog Audio I/O | 4 x 1/4" TRS Balanced Input (2 Stereo Pair) 1 x 1/4" TRS Unbalanced Stereo Input 6 x 1/4" TRS Unbalanced Headphone Output |
Performance
| Frequency Response | Inputs: 10 Hz to 40 kHz ±1 dB Outputs: 10 Hz to 70 kHz ±1 dB |
| THD+N | < 0.05% |
Physical
| Rackmount Size | 1 RU |
| Dimensions | 19 x 5.5 x 1.75" / 483 x 140 x 44 mm |
| Weight | 5.0 lb / 2.3 kg |
