Product Description
Phase Technology CS-8R 8" 2-way In-Ceiling Speaker
Overview
8 inch Coax In-Ceiling Speaker w/ Micro-Flange Grille. The CS-8R is engineered to handle the dynamic range of multi-channel audio technologies as well as traditional two-channel sources for outstanding reproduction of movies and music. The .75 inch pivoting tweeter allows the speaker to be properly aimed at the listener in off-axis mounting situations while the 8 inch coaxial polypropylene cone with butyl rubber surround offers fantastic mid and low-end frequency performance. The CS-8R was designed to be unobtrusive to a room's aesthetics with its paintable magnetic micro-flange grille and a bezel that is nearly invisible. The CS-8R pairs with Phase Velocity®'s V626.
Specifications
| UPC | 748252171566 |
|---|---|
| Manufacturer | Phase Technology |
| Manufacturer's Category | CS Professional Series |
| Depth | 3.8 in / 96.52 mm |
| Width/Diameter | 10.6 in / 269.2 mm |
| Shipping Weight | 5.5 lbs / 2.49 kg |
| Carton Height | 5.5 in / 139.7 mm |
| Carton Length | 12 in / 304.8 mm |
| Carton Width | 12 in / 304.8 mm |
| Enclosure Properties | Infinite Baffle |
| Included Accessories | Grille, Hole Template |
| Optional Accessories | Pre-Construction Bracket (RB22) |
| Source Inputs | Metal Push Binding Posts |
| Cutout Depth | 3.38 in / 85.9 mm |
| Cutout Width/Diameter | 9.63 in / 244.6 mm |
| Frequency Response (± 3 dB) | 42 Hz - 20kHz |
| Grille Properties | Flangeless, Magnetic, Powder-Coated, White, Paintable |
| Nominal Impedance (Ω Ohms) | 8 Ω |
| Tweeter Driver | .75" Variable Axis Soft Dome |
| Woofer Driver | 8" Coaxial Polypropylene w/ NBR Surround |
| Recommended Power | 5-120 W |
| Sensitivity dB @ 2.83V/1M | 87 dB |
