Product Description
PCI KEEPER NW KIT Keeper Enterprise Kit Networked
Top Product Features
• Keeper Enterprise is an accessory programming software for Greengate network and stand-alone panels. The PC software allows the user to easily organize the lighting system into multiple sites, networks and buildings. Keeper Enterprise is an off-line editor allowing programming edits and maintenance to be performed when not connected to the network.
• Off-line editor allows programming of your lighting control system when not connected to the system
• Real-time control and status of all lighting control points
• Organize your lighting control system into multiple sites, buildings or networks
• Permits remote access to the lighting control network via the Ethernet Interface Module (EIM) accessory
• Each Network permits the ability to have a dedicated IP address for communications
• Back up and restore functionality
Product Specifications
Key Features
• The Keeper Enterprise software accessory provides access to network and stand-alone lighting control panels
• The software permits the user to upload and download programs files, control relays, check relay status, check relay run-time, view logs and more with an easy user interface • Panel program files can be created, altered and archived on the computer
• The tree structure allows you to organize your panels into sites, networks and buildings
• Right click on a panel, building or network to communicate to your lighting control panels
• The Keeper Enterprise can communicate via serial, modem and TCP/IP communications
Supported Operating System:
• Windows 10 and below - 32 & 64 bit
• USB flash drive
• Network card
Software Capabilities by Panel Type ControlKeeper 2 & 4:
• Name descriptor
• Panel address and communication method
• Define, broadcast and log low votlage and digital input information
• Define, broadcast and log Output information
• Link inputs and outputs for functional programming
• Configure Remote network listener commands (to take action based on inputs from other panels on the network)
• Copy/paste already programmed panels for template driven programming
ControlKeeper 4A:
• Name descriptor
• Panel address and communication method
• Define, broadcast and log low votlage and digital input information
• Define analog inputs
• Define analog outputs
• Define, broadcast and log Output information
• Link inputs and outputs for functional programming
• Configure Remote network listener commands (to take action based on inputs from other panels on the network)
• Copy/paste already programmed panels for template driven programming
ControlKeeper T:
• Name descriptor
• Panel address and communication method
• Define, broadcast and log low votlage and digital input information
• Define anlaog inputs
• Define, broadcast and log Output information
• Link inputs and outputs for functional programming
• Configure Remote network listener commands (to take action based on inputs from other panels on the network)
• Copy/paste already programmed panels for template driven programming
Room Controller Network:
• Name descriptor
• Panel address and communication method
• Panel firmware updates over the network
• Define, broadcast and log Output information
• Define daylight gain settings for three dimming zones
• Adjust High End/Low End trim settings for each panel
• Adjust Demand Response values for each panel
• Configure Remote network listener commands (to take action based on inputs from other panels on the network)
• Configure scene values for each panel
• Copy/paste already programmed panels for template driven programming
