Product Description
Pathway Connectivity PWVIA RM P12 RJ45EC QUAD POE VIA12 TE Gigabit Ethernet Switch - 12 Port, opticalCON Quad (Old Part #6754-P)
VIA12 TE (models 6752-P and 6754-P) are gigabit Ethernet switches designed specifically for lighting, sound and video signal routing in live entertainment applications, including live shows. With built-in opticalCON DUO (model 6752-P) and opticalCON QUAD (model 6754-P) fiber connectors for LC multimode fiber.
Unlike switches designed and marketed for office and communication applications, VIA12 TE ships as an unmanaged switch, pre-configured and optimized for entertainment network use, with twelve etherCON RJ45 copper ports and two opticalCON DUO (6752-P) or QUAD (6754-P) locking connectors for multi-mode fiber. When needed, VLANs, EAPS, RSTP and other Layer 2/3 management features are easily accessed and configured through the front panel interface and the Pathscape software suite. 100W of power is available on board to supply PoE-enabled devices.
- Trap Art-Net and convert it to sACN
- IGMP querier and snooping, DHCP per VLAN
- Dante-compliant QoS option
- Illuminated LCD display and rotary encoder for displaying and setting switch and port properties
- Global properties editable from front panel interface: IP Address, Subnet Mask, Default Gateway, VLAN configuration
- Properties displayed by front panel interface: Switch Name, Port Name, PoE usage, Serial Number, MAC address, firmware version, connected devices (LLDP compliant), link status and speed, bandwidth monitor
- EAPS—Ethernet Automatic Protection Switching (rapid ring failure detection and correction)
- Link Layer Discovery Protocol (LLDP)
- Twelve locking etherCON RJ45 ports (ten on front panel, two on rear) support 10/100/1000Base-T speeds
- Two locking opticalCON ports on rear panel support multi-mode LC fiber optic lines
- Wide range input power supply with powerCON In and Thru accommodates all countries mains voltage and frequency
- 1 RU high housing with integral rack ears fits 19” rack
- Integrated 100W PoE supply for powering compatible external devices
- Up to 15W of PoE may be alloted to each copper port
- Thermostatically-controlled cooling fans
Specs
- 100-240VAC wide-ranging power input
- Powercon AC Input and Through connectors (DO NOT CONNECT MORE THAN 6 VIA TE SWITCHES TOGETHER ON ONE AC INPUT)
- Operating conditions: 14°F to 122°F (-10°C to +50°C), 5-95% relative humidity, non-condensing
- 1.3A maximum power consumption (or 11.3A maximum while using AC Thru - DO NOT EXCEED 10A DRAW THROUGH FIRST SWITCH)
- 5.2 lb (2.4 kg)
- 17 x 12 x 1.7 in (432 x 305 x 40mm)
- Compliance
- IEEE 802.1AB Link Layer Discovery Protocol
- IEEE 802.3af—Power over Ethernet
- California Title 1.81.26 Security of Connected Devices
