Product Description

Pathway Connectivity PWGW DIN CLK Architectural Gateway, DIN-mount, Vignette Clock (4.5") (Old Part #0700-5481)

Vignette™ Clock is a powerful expansion device for Vignette systems, allowing you to automate playback of snapshots, zones, and other Vignette functions based on date, time, or astronomical events such as dawn, dusk, sunrise or sunset. Extensive configuration options in the free Pathscape software allow fine-tuning of the desired playback events. Set up schedules for each day, and select different looks for mornings, afternoons or evenings; on weekdays or weekends. Comprehensive scheduling for specific dates and date ranges. Input the local timezone and geographical location for accurate astronomical event timing, without having to make any additional adjustments.

Features

• Expands functionality of Vignettebased systems to automate playback of snapshots, zones, grandmaster level, and other Vignette functions
• Specify hour, minute, second, year, month, day of the week, or any range of these (contiguous or noncontiguous) to trigger snapshots and Vignette functions automatically
• Synchronize with astronomical events to trigger snapshots or functions at dawn, sunrise, dusk, or sunset, any day of the year
• Can subscribe to NTP (Network Time Protocol) server to keep time accurate
• Internal battery maintains clock accuracy during any power outages
• Can snapshot up to 4 Universes of sACN on its own and play back without any other Vignette wall stations
• Operates on Power-over-Ethernet (PoE) or auxiliary 24-48VDC input
• Requires free downloadable Pathscape software for configuration
• Mounts to standard 35mm DIN rail

Accessories

• PWPWR DIN TERM 100W 48VDC Power Supply, DIN-mount, Compression Fit Terminal, 100 Watts, 48 Volts DC
• PWENC SHELF HOR DIN System Enclosure, 2-RU Shelf unit with 2x16.5", Horizontal Rails
• PWENC SML VER DIN System Enclosure, Small 10" x 13" x 4.5", Vertical Rails
• PWENC MED VER DIN System Enclosure, Medium 10" x 23" x 4.5" , Vertical Rails
• PWENC SML HOR DIN System Enclosure, Small 10" x 13" x 4.5", Horizontal Rails
• PWENC MED HOR DIN System Enclosure, Medium 10" x 23" x 4.5" , Horizontal Rails
• PWENC LRG VER DIN System Enclosure, Large 18.5" x 31.5" x 6.25", Vertical Rails
