Product Description
Pathway Connectivity PWENC LRG VER Expanded eDIN System Enclosure with Three 24" Vertical DIN Rail (Old Part #1109)
The 1109 Expanded Pathway eDIN Enclosure is an ETL-Listed NEMA1 Enclosure for eDIN modules with power supplies. Fits up to 9 large (8.0" / 204mm) eDIN modules. Fit an entire system in one box!
NOTE: This system enclosure cannot be factory pre-wired.
Features
- Contractor friendly, sturdy steel construction
- Conduit knockouts provided on all sides
- Logical arrangement makes wiring neat and easy
- Barriered high-voltage section for power supplies (power supply not included)
- Internal 35mm DIN rail can be used to mount eDIN and other standard DIN rail modules
- No cooling fan required
- 3-gang cutouts on front door with blank cover plates (Choreo, Choreo NSB and accessories shown installed in door not included)
- Removable hinged door
- Black powder-coat finish
Specs
- DIN Rail: 3 x 24" (630mm) vertical sections
- Conduit knockouts: 4 on left/right sides; 2 on top/bottom
- 18.5" x 31.5" x 6.25" (470mm x 343mm x 159mm)
- 42.5 lbs (19.3 kg)
- Compliance
- ETL-listed
- RoHS 2011/65/EU
