Product Description
MegaLite 4460 Paramount Pendant Q350 200W RGBWW Parnel Down Light
MEGA-LITE’s determination is to develop innovative, unique fixtures that will give integrators and lighting designers the tools to expand their creativity. The distinctive Paramount Pendant Q350 does just that by bringing pendant lighting to a new dimension.
This over 3ft fixture is equipped with a 200W RGBWW parnel down light and 150W RGBWW radiating cylinder light. It is a powerful pendant that was designed to illuminate mid to large applications.
With a total of 16 segments of control the unit features 15 segments on the cylinder and 1 element on the down light. This 360º function creates multidimensional radiating color changing effects that can be used for very traditional or captivating applications. The optional 18º an 28º beam angle lenses give the ability to customize the beam based on the size of any room.
The Paramount Pendant Q350 was created with an integrated wireless solution and innovative design that allows it to be hardwired for permanent installation or quick disconnect, ideal for touring. It can be accessorized with a decorative cover for a more elegant finish.
Add a new dimension to your designs with the Paramount Pendant Q350.
SPECIFICATIONS:
SOURCE | |
---|---|
DOWN LIGHT LED TYPE: | 1 COB LED 200W |
CYLINDER LED TYPE: | 90 SMD LED 1.5W |
LENS ANGLE | 10º |
DOWNLIGHT & CYLINDER COLOR: | RED, GREEN, BLUE, WARM WHITE |
SEGMENT CONTROL: | 15 CYLINDER SEGMENts, 1 Downlight element |
WIRELESS DMX: | WIRELESS SOLUTION RECEIVING |
DISPLAY: | DIGITAL |
PROTOCOL: | DMX 512, RDM |
DMX CHANNELS: | 5 MODES OF OPERATION |
RDM | YES |
TOP & BOTTOM HOUSING MATERIAL: | METAL |
CYLINDER HOUSING MATERIAL: | ACRYLIC |
MAX AMBIENT TEMP: | 104º F / 40º C |
MAX SURFACE TEMP: | 140º F / 60º C |
POWER CONSUMPTION: | UNIVERSAL 100-240V 50/60HZ |
POWER CONNECTION: | PANEL MOUNT NEUTRIK TRUE POWER ONE CONNECTION/SCREW TERMINAL for permanent install |
DMX CONNECTORS: | XLR 5PIN IN & OUT/ SCREW TERMINAL FOR PERMANENT INSTALL |
INSTALLATION SYSTEM: | MOUNTING bracket |
SECONDARY SAFETY: | 1” EYE BOLT |
PARTS:
PART NAME: | PART ID: |
---|---|
PARAMOUNT PENDANT | 4460 |
DECORATIVE COVER BLACK | 4460ACCDEC |
18º LENS | 4460LEN18 |
28º LENS | 4460LEN28 |
2 UNIT ROAD CASE | CAS44602 |
REPLACEMENT LED COB 200W | 4460LED200 |
REPLACEMENT LED SMD 1.5W | 4460LED1.5 |
SIDE LED MODULE | 4460LEDMOD |
200W LED DRIVER | 4460PCBDRI |
MAIN PCB/DISPLAY | 4460PCBMAI |
WIRELESS SOLUTION PCB | 4460PCBWIR |
VOLTAGE PCB | 4460PCBVOL |
FRESNEL LENS | 4460LENFRE |
PRIMARY LENS | 4460LENPRI |
POWER SUPPLY | 4460POW |
FAN | 4460FAN |
WIRELESS ANTENNA | 4460ANT |
CLAMP MOUNT | 4460HOUCLA |
HOUSING ACRYLIC | 4460HOUACR |
ACCESSORIES:
MegaLite 4460-LEN-18 Paramount Pendant 18º LENS
MegaLite 4460-LEN-28 Paramount Pendant 28º LENS
MegaLite 4460-ACC-DEC Black Decorative Cover for Paramount Pendant
