Product Description
MegaLite 1220 MB1 80W LED Beam Moving Head Fixture
ACCESSORIES:
The MB1 is part of the M-Series. MB1 is a powerful beam moving head. It houses an 80W LED, this compact unit has the capability of projecting a strong output and long throw. It is equipped with an 8-facet circular and 6 facet linear prism that can create a unique aerial effect. The unit features a frost filter, remote focus, fixed gobo wheel and color wheel that can be used to generate a variety of color and visual combinations. The MB1 can be used in multiple applications such as mobile DJ, church, theater and even club environments.
SPECIFICATIONS:
ITEM ID: | 1220 |
---|---|
LIGHT SOURCE: | 80W LED |
PAN: | 540° 8/16 bit 3 Phase Motors |
TILT: | 270° 8/16 bit 3 Phase Motors |
DMX CONNECTORS: | 3 and 5-pin XLR Connectors |
POWER CONNECTION: | Power Con Type In/Out |
THERMAL: | Maximum Ambient Temperature 110º F Maximum Surface Temperature 140º F |
FASTENING SYSTEM: | 2 Quick Release Bi-Directional Clamp Mounts |
POWER SWITCH: | On/Off |
POWER SUPPLY: | Auto Switching 100V≈240V 50/60Hz |
POWER CONSUMPTION: | Watts: 210W / Amps: 2.94 |
BALLAST: | Electronic |
DISPLAY: | LCD Display |
SHUTTER: | Electronic Shutter Strobe 18 Flash Per Second |
ANGLE: | .85º |
FIXED GOBO: | 9 Fixed Gobos + 2 Beam Reducing Gobos |
PRISM 1: | 8 Facet Circular Prism |
PRISM 2: | 6 Facet Liniar Prism |
MULTI COLOR: | 6 Color Multi Color Effect |
FROST: | Soft Frost Effect |
FOCUS: | Mechanical Focus |
COLOR: | 13 Colors + Open |
ACCESSORIES:
MegaLite CAS-1210-4 Four Unit Road Case
PARTS:
PART NAME: | PART ID: |
---|---|
MB1 | 1220 |
LED Replacement | 1220-LED |
LED Driver Board | 1220-PCB-DRI |
Display PCB | 1220-PCB-DIS |
Pan Band | 1210-BAN-PAN |
Tilt Band | 1210-BAN-TIL |
DMX Connections | 1215-CON-DMX |
24VFan 3.6 | 1220-FAN-24V-3.6 |
24VFan 4.8 | 1220-FAN-24V-4.8 |
Quick Release Mount | 1210-HOU-QUI |
Power Supply | 1220-POW |
4 Unit Road Case | CAS-1210-4 |
