Product Description
MDG MDGATMEWPE ATMe Weather Proof Generator
THE FINEST HAZE ON THE MARKET… LOVES RAINY WEATHER
The ATMe WPE is the weatherproof version of the ATMe haze generator, and the perfect solution for theme parks, outdoor festivals and events, come rain or shine.
FEATURES
-
EXTREMELY QUIET OPERATION
Noise emission (at 1m/3.3ft): 45.4 dB in standard mode. The theatre mode reduces the fan speed depending on haze output level.
-
LOWEST FLUID CONSUMPTION ON THE MARKET
At 1.38 bar (20 psi) ATMe uses only 55 ml (1.86 oz) of fluid per hour to give a total running time of 46 hours from its 2.5 L (0.66 US gallon) reservoir.
-
LONGEST HANGING TIME
Our MDG Neutral fluid is specially created for the longest hanging time.
-
VARIABLE HAZE OUTPUT
0-100% haze output control from your DMX / RDM device. 100% duty cycle.
-
APS™ (AUTOMATIC PURGING SYSTEM)
This system purges the heating module after the first heating cycle and after every emission of haze preventing residual build up and clogging.
-
NUMEROUS CONTROL OPTIONS
4-button LCD user interface, 3 standard USITT DMX512 channels, XLR-5 connectors, RDM compliant.
-
WEATHERPROOF ENCLOSURE
With its weatherproof and dust-resistant enclosure this IP55-rated WPE version is ideal for outdoor use.
SPECIFICATIONS
Fluid consumption
55 ml (1.86 oz) per hour at 1.38 bar (20 psi)
110 ml (3.3 oz) per hour at 2.76 bar (40 psi)
CO2 consumption
0.18 kg (0.4 lb) per hour at 1.38 bar (20 psi)
0.36 kg (0.8 lb) per hour at 2.76 bar (40 psi)
Reservoir capacity
2.5 L (0.66 US gallon)
APS™ (Automatic Purging System)
Standard
Haze colour
Pure white
Particle size
0.5 - 0.7 micron
Total running time
46 hours at 1.38 bar (20 psi) with a full tank
23 hours at 2.76 bar (40 psi) with a full tank
Warm-up time
8 minutes (maximum)
Fluid type
MDG Neutral
Operating voltage
100 - 250 VAC, 50/60 Hz single phase
Power consumption
715 W
Noise emission
45.4 dB (A) at 1 m (3.3 ft)
Enclosure
Weatherproof and dust-resistant
IP55-rated
DIMENSIONS
Length
46.7 cm (18.4”)
Width
48.8 cm (19.2”)
Height
60.7 cm (23.9”)
Weight
26.8 kg (59 lb)
Shipping weight
35.8 kg (79 lb) with flight case
Approval
CB, CSA and UL Certified. CE Declaration
