Light Source
- 1150 W proprietary LED light engine
- 84 x 20 W white LEDs
- Minimum LED lifetime: >50,000 hours (see specs for further details)
Photometric Data
- Light Engine Luminous Output: 90,000 lumens
- Fixture Luminous Output: 63,500 lumens
- Peak Luminous Intensity: 5,000,000 cd
- CCT: 6000 K (+/- 250 K)
Optics
- 220 mm Front Lens
- 1:7 zoom range (6.8° - 47.5° beam angle)
Dynamic Effects
- 0 - 100% continuous dimming and strobe effects
- Choice of four dimming curves
- CMY color mixing
- Color temperature control (6000 - 2850 K)
- Color wheel with six interchangeable dichroic filters, including a Spectral Enhancement Filter
- 1:10 Zoom (hyper zoom); 1:7 Zoom (native zoom)
- Motorized frost
- Iris
- Variable edge control
- Pan: 540°
- Tilt: 268°
- P3 videomapping of fixture color and/or intensity (10 segments)
- Pre-programmed effects: Two ranges of pre-programmed FX
Cooling and Noise
- Low noise cooling system
- User-selectable output vs. sound level control
Construction
- Height (head straight up): 848 mm (33.4 in.)
- Height (maximum): 867 mm (34.2 in.)
- Weight: 39.0 kg (86.0 lbs.)
Control
- DMX-512 in/out
- Ethercon in/out for P3, Art-Net, sACN
- Built in Ethernet switch with fail-safe bypass
Specifications
*Figure obtained under manufacturer's test conditions
Light engine luminous output: 90,000 lumens
LED refresh rate : 3000 Hz
Standard
Fixture luminous output: 63,500 lumens
CRI (Color Rendering Index): 66 (+/- 3)
TM-30 Rf (IES TM-30-15 Fidelity Index): 66
TM-30 Rg (IES TM-30-15 Gamut Index): 95
CCT: 6000 K (+/- 250 K)
Peak Luminous Intensity: 5,000,000 cd
With Spectral Enhancement Filter at 5300 K
Fixture luminous output: 49,000 lumens
CRI (Color Rendering Index): 78 (+/- 3)
With CTO and Cyan at 3200 K
Fixture luminous output: 19,500 lumens
CRI (Color Rendering Index): 90 (+/- 3)
* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.
AC power: 200-240 V AC nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current at 230 V, 50 Hz: 17.0 A
Power Factor: 0.99 @ 208 V / 230 V / 240 V
Max current draw: 8.0 A @ 200 , 6.7 A @ 230 V / 240 V
Typical current draw: 6.6 A @ 208 V , 6.0 A @ 230 V , 5.7 A @ 240 V *
Power Consumption
Maximum: 1450 W
Typical: 1360 W *
Idle: 100 W *
* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Typical: full output white, no effects moving, regulated fan speed.
Idle: no output, no effects moving, regulated fan speed.
LWR = Lumen-to-Weight Ratio
