Product Description
Martin Lighting ERA 700 Performance IP 680W IP65+ LED Based Profile
Overview
Martin Professional’s ERA 700 Performance IP is specially designed for permanent outdoor entertainment use and can withstand extreme environmental conditions for greater immersive lightshows. It offers a comprehensive toolkit for lighting design, including a CMYC color mixing system, full curtain framing system, dual gobo wheels, dual prisms, dual frost, animation, and a wide range of new gobo selections. Standing at only 759mm in height with an output of 26,000 lumens and weighing below 40kg, it is a reliable workhorse, delivering the perfect lumen output needed for larger outdoor shows and rental and installation applications. It is ideal for a wide range of architainment needs.
Designed around extreme environmental conditions, the ERA 700 Performance IP has the ability to work flawlessly from -20 degrees Celsius to +40 degrees Celsius, with C5M marine-grade salinity protection against harsh elements. The innovative active humidity control system maintains optimal humidity levels within the unit, preventing moisture-related issues and ensuring consistent performance.
This fixture also introduces several ground-breaking features that champion its functionality and security. It incorporates an anti-tamper box, preventing unauthorized access which also adds additional environmental protection increasing ingress protection to IP66.
Martin Professional’s ERA 700 Performance IP caters to the evolving needs of rental and installation markets. Its IP66 rating eliminates the need for outdoor protection domes, and its extensive feature set and robust design offers lighting designers and system integrators a reliable solution for long-term outdoor projects.
Features
- 26,000 lumen output via 680W 6,500K light engine
- IP65 (IP66 with anti-tamper box installed)
- CMYC Color Mixing system
- Zoom 5.4˚ to 44˚
- 1 x Rotating Gobo Wheel delivering 7 all new designs
- 1 x Static Gobo Wheel delivering 8 all new designs
- 1 x Animation wheel (new design)
- Color Wheel with Spectral Enhancement filter pre-installed (CRI 90)
- Full curtain framing system
- 2 x Prism (Linear and circular)
- 2 x Frost (heavy and medium)
- Iris
- DMX/RDM and Art-Net/sACN via network with bypass
- Weight 39.7 kg
- Height 759 mm
- Available in black and white
Specifications
Physical
- Weight: 39.7 kg (87.3 lbs.)
- Length (head): 542 mm (21.3 in.)
- Length (base): 436 mm (17.1 in.)
- Width (base): 314 mm (12.3 in.)
- Width (across yoke): 450 mm (17.7 in.)
- Height (head straight up): 759 mm (29.8 in)
- Height (maximum): 767 mm (30.2 in)
- Color mixing: CMY, independently variable 0-100%
- Color wheel: 7 color filters plus open (incl, Spectral Enhancement Filter)
- Gobo animation: Animation wheel, indexing, continuous rotation with variable speed and direction, shake (flow)
- Rotating gobo wheel: 7 gobos plus open, wheel rotation, gobo rotation, indexing and shake
- Static gobo wheel: 8 gobos plus open, wheel indexing, rotation and shake
- Iris: 0-100%Framing: Rotatable framing module, +/-60°, with 4 individually controllable full framing blades with variable angle and position.
- Prism: 2 rotating/indexing prisms (4-facet circular prism and 6-facet linear)
- Frost: Soft frost effect and heavy frost effect
- Color temperature control: Variable 6500 - 2700 K
- Electronic dimming: 0 - 100%, four dimming curve options
- Electronic shutter effect: Strobe effect, pulse effects, instant open and blackout
- Zoom: Motorized
- Pan: 540°, coarse & fine control and speed
- Tilt: 270°, coarse & fine control and speedFocus: Motorized
Control and Programming
- DMX channels: Basic 42 Extended 54
- DMX compliance: USITT DMX512/1990
- RDM compliance: ANSI/ESTA E1.20
- Control options: DMX, RDM, Art-Net, sACN
- Protocol detection: Automatic
- 16-bit control: Dimming, CMY, CTO, Zoom, Focus, Framing, Gobo Rotation/Indexing, Pan and Tilt
- Setting and addressing: Control panel with backlit LCD display and battery powered operation
- Art-Net Compliance: Art-Net 1, 2, 3 and 4; including RDM over Art-Nets
- ACN Compliance: ANSI E1.31 - 2016
- Transceiver: Opto-isolated RS-485
Optics
- Front lens diameter: 120 mm (4.75 in.)
- Zoom range: 5.4 to 44 (1:8)
- Light source: 680 W LED engine
- Minimum LED lifetime: 20000 hours (to >70% luminous output)*
- Binning: Tight color and flux binning
*Manufacturer's figure obtained under manufacturer's test conditions
Photometric Data
- Light engine luminous output: 41,600 lumens
- LED refresh rate : 3600 Hz
- Fixture luminous output: 16,420
- CRI (Color Rendering Index): 90
- CQS (Color Quality Scale): 88
- TM-30 Rf (IES TM-30-15 Fidelity Index): 87
- TM-30 Rg (IES TM-30-15 Gamut Index): 106
- TLCI (Television Lighting Consistency Index): 73
- CCT: 6400 K (+/- 250 K)
- Peak Luminous Intensity: TBA
- Fixture luminous output: 26,000 lumens
- CRI (Color Rendering Index): 70
- CQS (Color Quality Scale): 68
- TM-30 Rf (IES TM-30-15 Fidelity Index): 71
- TM-30 Rg (IES TM-30-15 Gamut Index): 94
- TLCI (Television Lighting Consistency Index): 46
- CCT: 6500 K (+/- 250 K)
- Peak Luminous Intensity: 1393059 Cd (narrow
- Housing: Recyclable high-impact flame-retardant thermoplastic and cast aluminum
- Color: Black & White
- Protection rating: IP 65 (IP 66 with anti-tamper box installed)
- Corrosion resistance: C5-M (very high corrosivity / marine, ISO 12944)
- Maximum image diameter: 19 mm (0.75 in.)
- Gobo material: Borofloat 33
- External diameter: 23.0 mm +0 / -0.2 mm (0.906 in. +0 / -0.008 in.)
- Maximum gobo thickness: 1.1 mm (0.04 in.)
- Coating: Speciality coating including CT correction
- Mounting points: 2 pairs of 1/4-turn points for 106 mm (4.17 in.) center-to-center omega brackets
- Location: Wet locations, must be fastened to surface or structure
- Orientation: Any
- Minimum distance to combustible materials: 0.2 m (8 in.)
- Minimum distance to illuminated surfaces: 2.0 m (6.6 ft.)
- DMX and RDM data in/out: 5-pin locking XLR
- AC mains power input.: TRUE1 compatible socket, accepts TRUE1 NAC3FX-W (TOP) connector
- Ethernet Art-Net, sACN in/out, including fail-safe bypass: Neutrik etherCON
- AC power: 100-240 V AC nominal, 50/60 Hz
- Power supply unit: Auto-ranging electronic switch mode
- Typical half-cycle RMS inrush current at 230 V, 50 Hz: 14A
- Power factor: 0.97
- Typical current draw: 100-120V 11.1A 200-240V 3.7A
- Max leakage current: 0.43 mA
- Maximum: 990 W
- Typical: 856 W *Idle: 114 W
- Hibernation: 15 W
- Cooling: Forced air (temperature regulated, low noise)
- Total heat dissipation (calculated, +/- 10%): 3375 BTU/hr
- Maximum surface temperature, steady state, at 40° C ambient: 75° C (167° F)
- Maximum ambient temperature (Ta max.): 40° C
- Minimum ambient temperature (Ta min.): -20° C
- Sound Pressure Level (LpA) @ 1 m (default regulated fan mode, full output): 44.3 dB(A)
- Sound Pressure Level (LpA) @ 1 m (constant fan mode ultra low): .38.3 dB(A)
- RoHS: Compliant
- REACH: Compliant
- WEEE: Compliant
- Proposition 65: Compliant
- Efficacy (max output): 29.6 Lm/Watt
- LWR*: .655 Lm/Kg
*LWR = Lumen-to-Weight Ratio
Included Items
- Two omega brackets with 1/4 turn fasteners for rigging clamp attachment: 2 x P/N 91602001
- Anti-Tamper Environmental Protection Box
