Product Description
Martin Lighting ELP PAR Static RGBW LED PAR with Zoom
Overview
The Martin ELP PAR static LED fixture sets a new standard in the static wash category, with unprecedented lumen output, high-intensity narrow zoom, full-gamut color calibration and smart rigging and control features.
The ELP PAR makes installation faster and easier, thanks to a quick-focus system and bright angle of projection indicators. Other performance enhancements include a wide zoom range that allows both stage illumination and tight mid-air beam effects, an advanced color-calibration system that delivers accurate color reproduction and precise color temperature control, an extended color mode and a CTC channel that allows RGB color mixing around your desired white point.
Whether lighting a theatre production, festival, exhibition or corporate event, fill the stage with color and create stunning beam effects with this versatile LED fixture that sets a new performance benchmark in its class.
Brightness that goes the distance
The ELP PAR delivers a class-leading 3,500 lumens of output—double the brightness of the previous generation—thanks to its newly designed 7 x 40W RGBW light engine. It’s perfect for covering larger stages that require long throw distances.
Smart Setup Features
Streamline setup with smart rigging and control features, including omega-bracket-connectivity and bright angle of projection indicator marks for quick and repeatable installation. With the push of a button, the fixture temporarily switches to full-power/open-white/adjustable-zoom settings to instantly confirm projection and focus.
High-Intensity Zoom
ELP PAR ’s next-generation zoom system excels at creating both broad washes and high-intensity mid-air effects, bringing new flexibility to the lighting designer’s toolbox.
Full-Gamut Color Calibration
The ELP PAR features a full-gamut color-calibration system, which allows consistent color reproduction from fixture to fixture and supports a dedicated color temperature control channel for adjusting the color space from the desired color temperature.
Features
- Light engine: 7 x 40W RGBW
- Full-gamut color-calibration system
- CTC control: 1,800–12,850 K
- Lumen output: 3,500 lm
- Intensity: 390,000 cd
- Zoom: 4.2 - 58°
- Quick Focus mode allows installation and focusing without the need for a console operator
- Clear of projection indicators allow quick installation
- Angled power and data connections support a clean cable run that does not impede the fixture or installation
- Included truss and floor-mounting yoke with omega bracket connectivity
- Low-noise 33 dB Theatre mode operation
- IP20 rating
- Dimensions: 312 x 287 x 401 mm (12.3 x 11.3 x 15.8 in) (inc. bracket)
- Weight: 7.8 kg (17.2 lbs.)
Specifications
*Figure obtained under manufacturer's test conditions
*All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.
AC power: 100-240 V AC nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current at 240 V, 50 Hz: 8.7 A
Power Factor: 0.99 @ 100 V / 120 V , 0.94 @ 220 V / 230 V / 240 V
Typical current draw: 3.0 A @ 100 V / 120 V , 1.7 A @ 220 V / 230 V / 240 V *
Power Consumption
Typical: 300 W *
* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Typical: full output white, no effects moving, regulated fan speed.
Thermal
Maximum surface temperature: 65° C (149° F)
Cooling: Forced air (temperature regulated, low noise)
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): -10° C (14° F)
Total heat dissipation (calculated): 1170 BTU/hr.
LWR = Lumen-to-Weight Ratio
Adjustable mounting bracket
Safety and Installation Manual
