Product Description
LynTec RPCR-16 RPC Relay Panel with 16 Single-Pole 20A Panasonic Relays
Overview
LynTec RPCR Relay Panels are some of the most complete self-contrained electrical relay panels available. This model, the RPCR-16 is a 16 single pole relay with Panasoinc 20A relays. The patent pending RPC control platform is available for controllable relay panels. Every RPCR panel is shipped as a complete hardware/software package and ready to install. Lighting control relay panels are robust and require less maintenance, and when they do need service they are centralized in the electrical control room within easy reach. Due to the surge in popularity, manufacturers have responded with a new generation of built in control capabilities and software features that provide a much better user experience.
This controller uses remotely operated circuit breakers to control up to 167 remotely operated branch circuits. In the case of the RPCR, the controller can control up to 64 relays. Control signals originate externally from commands received via the communications network or from dry contact inputs. Acceptable communications protocols include TCP/IP, RS-232, sACN and DMX-512, with RS-485 optional.
The LynTec RPCR Relay Panels utilize Panasonic 20A HID relays have been the industry standard for more than a decade. Their durable design provides reliable control for lighting and plugs loads and makes safety a priority. Panasonic relays are available for both single and double pole loads.
Features
- Built-in web server with browser interface for super-easy set up.
- No on-site commissioning required, and LynTec takes the trouble calls direct.
- Built in IP interface for smart phone, tablet or laptop control and monitoring.
- Built in scheduling program with astronomical clock and 84 schedule events.
- Built in contact closure inputs for wall or sensor operation (up to 38 inputs).
- Can be interfaced with any control system that communicates individual circuit addresses in DMX, sACN, HTTP, Telnet, BacNET or RS-232.
- Seamless integration into existing building management systems.
- Circuit selectable load-shedding feature standard.
- Circuit level sequencing with selectable step-rates standard.
- Circuit selectable auto-on egress lighting feature standard.
- Brownout (under-voltage) protection with automatic shut-down and controlled restart.
- ETL Listed to UL 508a and 924 standards.
Specifications
- Relay Model: PAN-1P
- Type: Single Pole HID Relay
- Item Number: WR6161K-84
- UL-Rating: Electrical Life
- Output Contact Side:
- General Use: 30A 300VAC
- Tungsten: 2400W 120VAC
- Ballast (Standard): 20A 300VAC
- Ballast (Electronic): 16A 277VAC
- Motor Starting, Single Phase:
- .5HP 110-125VAC
- 1.5HP 220-277VAC
- Auxilliary Contact Side:
- General Use: 1A 125VAC
- Short Circuit Rating: 18kA 277VAC
- Performance: 60k operations
