Listen Technologies LA-140 Stationary IR Radiator
Overview
The LA-140 Stationary IR Radiator from Listen Technologies is designed for use with the LT-82 transmitter and allows you expand your assisted listening system's infrared coverage. Each LA-140 covers up to 10,000 ft², and two units can be powered directly from the transmitter. The unit can also be powered from an LA-205 power supply (available separately).
The radiator is easy to install and hardware is included for mounting the unit to a wall, ceiling, desk, mic stand, or tripod. Power is supplied through Cat 5 cabling, with standard coaxial cabling for the RF signal. Two LA-140 units can be mounted together horizontally or vertically, doubling the power of your system without taking up an excessive amount of space. Built-in delay compensation allows you to make adjustments when using multiple LA-140 units together to prevent phasing problems and signal cancellation.
Features
- Expands Infrared Coverage Area
- For Use with LT-82 IR Transmitter
- Covers up to 10,000 ft²
- Mounting Hardware Included
- One LT-82 Can Drive Two LA-140 Units
Includes
- One (1) LA-140 Stationary IR Radiator
- One (1) Mounting hardware (allows for wall, ceiling, desk, mic stand and tripod mounting)
- Twenty-five (25) ft. (7.6 m) of coax cable, matched color
- Twenty-five (25) ft. (7.6 m) of CAT-5 cable, matched color
- One (1) Quick Reference Card
Specifications
| Buttons or Switches |
Termination Switch
Delay Compensation Switch
Indicator LEDs On/Off
Listen Mode
|
| LED Indicators |
1 x Power (Red)
1 x No Connection to Transmitter/Radiator (Yellow)
1 x Carrier and Power are Present, Emitting IR Signal (Green)
|
| Frequency Range |
1 to 5 MHz
|
| Coverage Area |
Up to 10,000 ft² / 929 m² When Used with Receiver
|
| Inputs |
BNC Connector (-25 dBm to -5 dBm Input Nominal)
RJ-45 Connector
|
| Outputs |
BNC Connector (-15 dBu Nominal)
RJ-45 Connector
|
| Power Supply |
Input: 30 VDC
Powered from LT-82 Transmitter or LA-205 Power Supply via CAT-5 Cable
Output: 30 VDC (Powers up to 1 Additional LA-140 Radiator)
|
| Emitter |
Power: 3 W
|
| Operating Temperature |
-14 to 104° F / -26 to 40° C
|
| Storage Temperature |
-4 to 122° F / -20 to 50° C
|
| Relative Humidity |
0 to 95% RH, Non-Condensing
|
| Approvals and Compliance |
FCC Part 15, Industry Canada, CE RoHS
|
| Dimensions |
5.5 x 8.0 x 2.6" / 14.0 x 20.3 x 6.6 cm
|
| Weight |
2.1 lb / 1.0 kg
Loaded: 2.4 lb / 1.1 kg
|
Other Details
Listen Technologies products are designed and engineered to provide longstanding use for many years. Listen Technologies warrants all products against defects in materials and workmanship. All product warranties can be transferred, in the event product is transferred the warranty is valid from the original date of the product purchase.
Listen shall bear no responsibility or obligation with respect to the manner of use of any equipment sold. Listen specifically disclaims and negates any warranty of merchant-ability or fitness of use of such equipment including, without limitation, any warranty that the use of such equipment for any purpose will comply with applicable laws and regulations. The terms of the warranty are governed by the laws of the state of Utah, USA.
Warranty does not include normal wear and tear on the product. In addition, Listen Technologies is not liable for consequential damages due to any failure of equipment to perform as intended.
Listen stands by the quality of its manufactured products and will, at its own discretion, repair or replace any defective products. All product warranties are subject to change without notice.
For all warranty related inquires and information please contact support at support@listentech.com.
