Product Description
Lightronics IDW104 Wall Mount DMX Opto-Isolator, DMX-512 SINGLE Universe Input to 4 Isolated Outputs, term strip
The IDW104 is an optically isolated DMX splitter with one DMX input and four independent DMX output circuits.
Specifications
- 1 DMX Universe
- 4 DMX Outputs
- Optical Isolation
- Protected Outputs
- Provided with UL Listed Power Supply
- Wall Mount
Options
- Portable (IDP104) or Wall Mount
Architect & Engineer’s Specifications
The splitter shall receive/transmit (1) universe of DMX512 by (5) pin, XLR type connector. The splitter shall display a valid DMX512 signal and power is present via LED indicator. Power shall be supplied to the device via an external, 12v-16v 800ma or greater power supply. The splitter shall be housed in a self contained, free standing, portable housing no greater than 6”x6”3”. The device shall split the DMX512 input to (4) DMX512 outputs. Each output shall be optically isolated, on each of (3) signal wires, D+, D- and ground. The optically isolated splitter shall be a Lightronics IDP104.
