Lexicon PCM96SUR-A Surround Parallel Stereo and Surround Reverb/Effects Processor w/ Analog & Digital I/O
Overview
Building on the success of the PCM96, the new PCM96 Surround offers more presets, more configuration options, and more inputs and outputs. The PCM96 Surround gives you industry standard reverbs and effects, with tremendous flexibility.
The PCM96 Surround is availble with either 6 XLR Stereo AES inputs and outputs, or 2 DB25 6-channel analog I/O and 1 DB25 6-channel digital I/O. Both versions also feature MIDI, and Wordclock.
Features
- 2 DB25 6-channel analog I/O and 1 DB25 6-channel digital I/O
- New Parallel Stereo and Sorround configurations
- 50 legendary Lexicon reverbs, delays, and modulation effects
- Lexicon's new Surround Room algorithm, used to generate a vast array of room-related effects for music and post
- New Pitch algorithms
- Over 2200 factory presets, including recognizable classics from Lexicon's immense library of sounds
- 32-bit floating point processing
- Sample rates up to 96kHz
- External BNC Wordclock
- MIDI in, out and thru
- 768 user presets
- Compact Flash for additional storage
Stereo And Surround Reverbs & Effects
|
Mono Reverbs & Effects
|
Specifications
Effects Type | Reverb |
Channels | 6 |
Effect Variations | Stereo and Surround: Room Hall Chamber Random Delay Classic (Random Hall) Plate Dual Delay Ambience Resonant Chords Chorus/Flange Concert Hall Signal Generator Pitch |
Presets | 2200+ |
User Memory | 768 internal 2048 on optional memory card |
Analog Input | 1 x 25-pin D-Sub |
Analog Output | 1 x 25-pin D-Sub |
Digital Input | 1 x 25-pin D-Sub (shared with output) |
Digital Output | 1 x 25-pin D-Sub (shared with output) |
Other Connectors | 2 x FireWire 2 x RJ-45 1 x BNC Wordclock input |
AD/DA Conversion | 24-bit |
MIDI | In/Out/Thru |
External Storage | Type I Compact Flash |
Display | High-resolution, high-contrast OLED |
Frequency Response | 20Hz to 46kHz, +0/-0.5dB @ 96kHz |
Dynamic Range | 112dB unweighted 115dB A-weighted |
Noise | THD: <0.002% 20Hz to 20kHz @ +4dBu |
Power Requirements | 100/120~220/240VAC, 50/60Hz |
Dimensions | 19 x 12.5 x 1.75" (483 x 318 x 45mm) |
Weight | 14.25 lbs (6.5 kg) |
Specialties | Seamless automation and control via Ethernet or FireWire |
