Product Description
Leviton PE-300-D0W power extender
Power Extender 0-10VDC Ballast Only, 20A 2400VA 120VAC, 5500VA 277VAC at 108 Volt AC to 305 Volt AC 60Hz, 0-10VDC Ballast Control
Leviton’s PE300 Power Extender allows a dimming zone’s power handling capacity to be extended to full control of a 20A circuit. The PE300 will drive 0-10VDC dimmable fluorescent ballasts such as Advance Mark VII 0-10V, OSRAM Sylvania Quicktronic Helios, or equivalent ballasts.
Features:
- Extends the power rating for dimmers
- Low end adjustment available for setting the minimum brightness level
- Works with Dimensions Multizone Controllers or Leviton box mount dimmers
The Leviton Mark VII power extender (catalog number PE300) is capable of extending the power capabilities of many Leviton wall box dimmers, as well as acting as a single channel for Leviton's dimming systems. It allows the control of fluorescent ballasts (0-10 volt dimming signal) from dimmers that normally cannot control such a load type. The power Extender incorporates a dimmer, a power supply, and a dim level measurement circuit.
UPC Code: 07847709190
Country Of Origin: Mexico
