Product Description
Leviton OSFHL-CTW Outdoor PIR Occupancy Sensor
Outdoor PIR Occupancy Sensor with IP65 Offset Adapter, Fixture Mounted, 21" wire lead length, Interchangeable Adjustable 360° Low Bay (8'-20'), and High Bay (20'-40') Lenses, Aisle Mask, 120V (800VA), 277V (1200VA), 347V (1500VA), 120/208/220/230/240/277/347V; 50/60Hz. IP65, Instant Start-up, Return-to-last state after power outage, Auto-Sensitivity gain from temperature increase, False-detection protection, Super Bright Green LED. CEC Title 20/24 compliant. Color: White
The Fixture Mount PIR High-Bay Wet Location External Occupancy Sensor (OSFHW) is ideal for damp or wet locations such as supermarket meat departments, food processing plants, parking garages and other wash down, high ceiling applications. The OSFHW features a IP65 rating for indoor and outdoor locations and is designed to withstand dust and pressure washers. The sensor comes with two interchangeable lenses for use in either a 360° high-bay or 360° low-bay general area and includes an aisle mask accessory.
Features
- IP65 Rated
- Quicksnap locking mechanism built into the 1/2” nipple allows for the fastest and easiest mounting not requiring a threaded lock-nut
- Unit includes interchangeable 360° high-bay (20-40’) and 360° low-bay (8-25’)lenses and an aisle mask accessory
- Time delay can be set can be set at any time without requiring power to the sensor; time delay is variable from 30 sec-30 min
- “Instant ON” closing relay fires lamps in under 5 seconds
- Zero crossing circuitry optimizes relay operation for reliable, long-life operationīrobust mechanical latching relay is durable for all load types
- Automatically adjusts the PIR sensitivity as ambient temperature rises to increase detection of heat movement through the field-of-view
- For safety and energy savings, the OSFHW contains a latching relay—in the event that power is lost to the device, the device will return to the last known state of the relay
- For increased energy savings and to mitigate nuisance tripping, the super-bright LED indicates advanced detection has been activated and the lights will only turn ON when true occupancy has been determined
Specs
- Color: White
- Product Line: OSFHL
- Sensor Type: Fixture Mount
- Technology: Passive Infrared
Electrical
- Input Voltage: 120-277-347VAC
- Operational Frequencies: 50/60 Hz
- Load Ratings
- 8000VA @ 120VAC Ballast
- 1200VA @ 277VAC Ballast
- 1500VA @ 347VAC Ballast
- Motor: 1/4 HP Load @ 120V
- Standby Power Consumption
- 120V - 130mW - .13W
- 277V - 450mW - .45W
- 347V - 460mW - .46W
- Time Delay: 30 sec - 30 min (factory set to 30 sec - no power required to set)
- Wire Designation: -ITW models: Line-Black, Load-Red, Neutral-White
Environmental
- Operating Temperature Range: -40 to 160°F (-40 to 71°C)
- Storage Temperature Range: -14 to 60°F (-25 to 71°C)
- Relative Humidity: 20 to 90% non-condensing
Physical
- Dimensions: OSFHW: 4.75" H x 3.75" W
- Construction: High-impact, injection molded plastic housing
- Color: White
