Product Description
Leviton ECS00-110 Emergency Power Control Switching loads only, 120-277VAC, 10A, 60Hz.
Emergency luminaire Control, switching loads only, 120-277VAC, 10A, 60Hz.
In the past, all designated emergency lights in a facility had to stay on 24 hours a day to meet safety codes. The Leviton Emergency Switching Luminaire Control allows you to specify and install a UL-924 listed emergency power control device that can convert and control up to 20 regular light fixtures as approved emergency lights. These emergency lights can then be turned ON and OFF in the same manner as regular lights. The Emergency Switching Luminaire Control automatically illuminates connected emergency loads to full brightness upon utility power interruption, regardless of switch/dimmer position.
APPLICATIONS
Ideal for emergency luminaires in public places such as:
• Auditoriums
• Restaurants
• Conference rooms
• Theaters
• Classrooms
• Retail spaces
• Municipal buildings
• Houses of worship
FEATURES
• Automatic Diagnostic—when the room switch is turned OFF, the emergency luminaires stay on for 2.5 seconds and indicate that an emergency power source is available and the equipment is functioning correctly
• Mounting—either flush mount or mount above a suspended ceiling in a single-gang plaster ring makes installation simple for varying applications
• Power Indicator—LED for utility power (green) for easy verification of normal power
