Product Description
Leviton DRDDP-A20 GreenMAX® DRC Phase Control 2 Channel Dimmer
Overview
The GreenMAX® DRC Phase Control 2 Channel Dimmer is used for incorporating 2-wire phase control loads into GreenMAX DRC systems.
System Description
The GreenMAX DRC Room Control System offers a fully distributed room control system, with each room operating independently of others—no dependence on network processors or centralized controllers. This revolutionary system is fully configurable via the GreenMAX DRC app for smart devices, and can be used to comply with IECC, ASHRAE 90.1, and 201 Title 24, Part 6 occupancy/vacancy sensing, multi-level lighting, daylight harvesting, partial-ON, partial-OFF, scheduling, exterior lighting, demand response and receptacle control requirements, and it is listed on the DesignLights Consortium (DLC) Qualified Products List (QPL) for Networked Lighting Control systems (certification pending).
Features
- Utilizes Leviton High Inrush Stability (H.I.S.) circuitry for increased reliability
- Connects via the LumaCAN® network via RJ45 connectors and CAT6 wiring
- SSL7 compliant dimming curve
- Forward or reverse phase control, multi-channel dimmer
- 2 wires, hot and neutral, per dimmer
- 120/230/277V operation; 50/60 Hz
- Each channel phase selectable—supports LED loads at full capacity
- LumaCAN network communication
- Single channel low voltage contact closure input (NOT analog input)
- Amplify feature—combine channels to increase output for occupancy sensor, momentary switch, or emergency
- Test button for each channel
- Level indicator of each channel
- Zero cross detection for longer dimmer life
- DIN rail installable for flexible enclosure selection (enclosure purchased separately)
Specifications
Electrical:
- Input Voltage: 120-277VAC, 50/60 Hz
- Max Input Current: 7A
- Power Consumption: 200mA, provided through line voltage input; No draw from LumaCAN bus
- LED,CFL, Electronic Ballast, Incandescent, Tungsten @ 120V: 3.5A (420W)/Channel (See channel ganging chart for additional details)
- LED,CFL, Electronic Ballast, Incandescent, Tungsten @ 277V: 3.5A (970W)/Channel (See channel ganging chart for additional details)
- Incompatible Load Types: Inductive, magnetic ballast, magnetic transformer, fans, motor
- Wire Size: Up to 12GA
Environmental:
- IP Rating/Enclosure: IP20, Type 1
- Operating Temperature: 32º to 140º F (0° to 60° C)
- Storage Temperature: -40º to 158º F (-40° to 70° C)
Connectivity:
- Network Connections: (2) RJ45, CAT6 or better for connection to LumaCAN network. Termination provided via local termination plug
- LumaCAN Network Power Consumption: 0mA
- Network Topology: Daisy chain, 1600’ max between repeaters Home-run topology and network length up to 10,000’ can be achieved when using LumaCAN network repeaters (NPRPT) Maximum 110 nodes between repeaters Maximum 250 nodes on a LumaCAN network
Other:
- Listings: UL, cUL (File # E148771)
- Energy Codes: Can be used to comply with IECC, ASHRAE 90.1, and 2019 Title 24, Part 6 occupancy/vacancy sensing, multi-level lighting, daylight harvesting, partial-ON, partial-OFF, scheduling, exterior lighting, demand response and receptacle control requirements
- DIN Rail Space: (1) DRDDP-A20 = 15 DIN rail units
- Warranty: 5-year
