Product Description
Leviton Centura CN220-C Switching Controller
Application The CN220 and CN221 controllers are Decora rocker-style devices for controlling fixtures within Leviton Control Network (LCnet) lighting systems. The CN220 Switching Controller is an on/off switch intended for non-dimming loads. The CN221 provides a familiar dual-rocker dimmer for adjusting brightness as well, and features LED’s indicating current light level. Since the CN220 turns fixtures on and off, it is ideally suited for entranceways and other areas where full-brightness lighting is required whenever lights are on. The CN221 is a strong option wherever a dimming controller is required. Both feature a locator LED and come in white with matching wallplates—with an ivory color change kit.
Operation CN220 The CN220 provides basic on/off control for non-dimming fixtures. Pressing the upper half of the rocker will turn lights on and pressing the lower half will turn them off. An LED underneath the rocker makes the switch easy to locate in the dark. The CN220 can be used to set its own LCnet address, as well as the address of nearby power packs.
Features and Benefits
GENERAL
• Extremely easy-to-use rocker design.
• Designer Decora styling enhances any décor.
• Locator LED makes switch easy to find, even in dark.
CN220
• Provides basic, on/off switch option for non-dimming LCnet loads.
Specifications
Electrical
Input Voltage: 24VDC Input Current: 24mA Power Consumption: less than 1W Testing/Code Compliance: UL Listed, CSA Certified, FCC Part 15, and California Title 24
Physical
Size: 4.13 x 2.38 x 1.59in. (10.5 x 6.1 x 4.0cm) Color: white (with matching wallplate and ivory color change kit for snap-on switch)
Environmental
Operating Temperature Range: 0ºC to +55ºC Storage Temperature Range: -10ºC to +85ºC Relative Humidity: 20% to 90% non-condensing
