Product Description
Lake People F622 Wordclock/AES-iD Splitter
Overview
Ideal for use in modern recording and broadcast studios, the DIGI-TOOL F622 from Lake People is a distribution amplifier and digital splitter designed to deliver up to 16 wordclock or AES-iD signals for one input. The F622 features two separate 24-bit modules, both with one unbalanced BNC input and eight unbalanced BNC outputs, and can be operated as either two separate 1x8 splitters or one 1x16 splitter.
The unit features high output voltages for maintaining signal strength over very-long distances, and a high input sensitivity helps to regenerate weak input signals. The F622 also sports failsafe operation thanks to its switchable multimode power supply, which automatically detects power input and switches to the appropriate voltage between 90 and 260 VAC.
High Voltages for Strong Signals
To address this issue, the F622 sports AGC amplifiers to produce 5 Vpp output signals for wordclock and 1 Vpp for AES-iD, more than enough to cover extremely long cable runs while maintaining optimal signal integrity. Both the inputs and outputs feature transformers for ensuring ideal signal strength, even allowing the unit to recover (regenerate) lost signal strength when receiving weak input signals.
Two Distinct Modules, One Elegant Design
- Jumpers for switching the output impedance from 75 to 50 ohms to drive improper wordclock inputs
- Jumpers to switch to AES-iD operation
- Jumpers that switch to Superclock 256 Fs
- Unbalanced BNC sockets with high input sensitivity and output voltages
- Clear LEDs for indicating if a module is active or no input signal is detected
Features
- For Studio and Broadcast Use
- Two BNC Inputs, 16 BNC Outputs
- 2 x 1-In/8-Out or 1 x 1-In/16-Out
- S/PDIF Wordclock and AES-iD I/O
- 24-Bit Operation
- High Input Sensitivity for Signal Regen
- Large Output Voltages for Long Cable Run
- Auto-Switching Multimode PSU
Includes
- LAKE PEOPLE DIGI-TOOL F622 Wordclock/AES-iD Splitter
- Power Cord
Specifications
| Audio I/O |
| Power Source | |
| AC Input Power |
| Certifications |
| Mounting | |
| Color | |
| Material of Construction | |
| Dimensions |
