Product Description
Kino Flo Image L40 DMX LED Panel with Pole-Op Mount
Key Features
- 54 x 6.5 x 17" Panel
- Variable Color Temperature: 2700-6500K
- Extended Range: 2500K-9900K
- CRI/TLCI: 95/98, Multiple Color Presets
- Hue, Saturation, and RGB Control
- Magenta/Green Control, Digital Display
- Local and DMX Dimming from 1-100%
- Built-In Wireless Lumen Radio DMX
- Flicker-Free, Silent Operation
- 100-240 VAC Power Supply
Overview
Flexibility and extensive control options are key to the production of the Image L40 DMX LED Panel with Pole-Op Mount from Kino Flo. The 54 x 6.5 x 17" panel employs four menus with several channels that have features that can be controlled on the light via traditional wired DMX or by Lumen Radio wireless DMX. The White menu allows control of 1 to 100% dimming, color control from 2700 to 6500K, and Green/Magenta control. There are two color menus. In the Gels/Hue menu, the Kelvin range is extended to 2500 to 9900K.
Among the channels is one called Gel that offers multiple presets for light conditions, such as mercury-vapor, and 100 often-used gel filters. A channel called Hue Angle (Hue) and another called Saturation (Sat) are also included in the Gel menu and function together like a 360-degree color wheel making over two million color combinations available.
The second color menu provides RGB (Red, Green, Blue) control, permitting a user-selected combination to obtain any color in the visible spectrum. The RGB menu also allows you to dial in specific gel RGB values or control colors from a DMX console. Finally, there's an FX menu that creates effects such as Candle, Fire, TV, Police, Lightning, Paparazzi, Pulse, and Scroll. Within each effect there are presets that vary the parameters or change the rate of the chosen effect.
The Image L40 is ready for worldwide use thanks to its 100 to 240 VAC power supply. The light comes with a 90-degree honeycomb grid to tighten its beam angle and limit spill light, providing directional control for selective lighting. This version of the light has a Pole Operated Mount for hanging overhead from a grid or pipe. Pan and tilt adjustments are made from below using a long pole.
Benefits
- Kelvin presets
- Dial-in color temperature control between 2700 and 6500K
- Extended color palette from 2500 to 9900K
- Green/magenta control
- Hue angle and saturation adjustments
- RGB control
- FX control
- Works with apps with predetermined RGB presets or color wheels
- Can use preset buttons to store custom Kelvin settings
- Light levels do not change when selecting Kelvin settings
- No color shift while dimming
- Color-correct with a high CRI/TLCI rating
- Universal power input: 100 to 240 VAC
- Energy efficient, draws 2A at 120 VAC
- Flicker-free, quiet operation
- Full range onboard and DMX dimming
- DMX wireless link: Lumen Radio
- DMX auto terminate
- Metal alloy fixture includes removable gel frame, louver, and cardholders
- Slim 6.5" profile
- Mounts to stand or can hang easily from a grid
Kino Flo L40 LED DMX Specs
Light Fixture
Item Type | 1 x LED Light Panel |
Photometrics | 519 fc / 5590 Lux at 3.3' / 1 m* 39 fc / 420 Lux at 12' / 3.65 m *Standardized Measurement Calculated Internally Based on Closest Distance |
Color Temperature | 2500 to 9900K |
Color Accuracy Standard | CRI 95 TLCI 98 |
Dimming | Yes, Built-In Dimmer 1 to 100% (Continuous) |
Expected Lamp Life | 50,000 Hours |
Front Accessory Mount | Proprietary |
Connectivity
Wireless Remote Control Type | Wireless DMX |
Power & I/O
Power Source | AC Power (Cable Included) |
Inputs/Outputs | 1 x IEC Power Input |
AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Included Adapter / Cable | 1 x Edison Plug to IEC Cable |
Inline Switch | No |
Power Pass-Thru | No |
Power Consumption | 200 W |
Mounting
Yoke Type | Pole-Operated Yoke |
Fixture Mounting | 1 x 1-1/8" Stud (Via Yoke Mount) |
General
Display | LCD |
Materials | Aluminum (Housing) |
Dimensions | 54 x 17 x 6.5" / 137.2 x 43.2 x 16.5 cm (Fixture) |
Weight | 27 lb / 12.25 kg (Fixture with Yoke) |
