Product Description
Kino Flo FreeStyle T42 LED DMX System Universal
Overview
This FreeStyle T42 LED DMX System Universal from Kino Flo features the FreeStyle T42 LED fixture and FreeStyle 120 LED DMX controller. It utilizes two 4' LED tubes and also includes the KinoGrip K41 Mount with 3/8" Pin, a 25' head extension cable, a US power cable, and a 2-pin Euro power cable.
Key Features
- FreeStyle T42 Fixture
- DMX Controller
- Gel Presets and FX Mode
- 2500-9900K Adjustable Color Temperature
- KinoGrip K41 Mount with 3/8" Pin
- 25' Head Extension Cable
- Multi-Voltage: 100-240 VAC
Kino Flo LED Tube for Freestyle T44 Fixture (4')
Specially designed for the fixture, the 4' LED Tube for Freestyle T44 Fixture from Kino Flo conforms to Kino's True Match white light and RGBW management system. It displays a soft, subtle light quality and accurate color rendition that earns it a CRI of 95. When used in the fixture with the reflector in a group of four, the output is similar to a 1000W tungsten soft light.
Kino Flo FreeStyle T42 LED Fixture
Featuring a compact and lightweight form factor, the FreeStyle T42 LED Fixture from Kino Flo offers the same Color Science LED technology found in all Kino Flo LEDs. This portable fixture can easily fit into tight locations or can be handheld with a separately purchased KinoGrip 41K mount. For mounting on light stands, the back of the fixture features a twist-on removable KinoGrip center mount, which can be adapted to work with multiple Kino Flo mounting adapters. The unit also comes with built-in barndoors and for additional light-shaping options, a reflector and 90° louver are included.
The FreeStyle T42 LED fixture requires a separately purchased LED tube, head cable, and DMX controller, and the controller features four individual modes: White, Gels/Hue Color, RGB Color, and FX. The White mode features dimming from 1 to 100% and a tunable range of 2700 to 6500K. In the Gels/Hue Color mode, the range is expanded from 2500 to 9900K. The gel channel also includes Kino Flo presets such as blue and green screen, sodium vapor, and mercury vapor, as well as over 100 well-known lighting gels. RGB Color mode gives individual control of red, green, and blue LEDs, and in FX mode you are provided access to popular effects such as candle, fire, TV, police, lightning, paparazzi, pulse, and scroll.
- Two 4' LED tubes in T42 LED Fixture
- Adjustable color temperature from 2500 to 9900K
- 1 to 100% dimming without color shifts
- Flicker-free and quiet operation
- Gel presets include blue and green screen, sodium vapor, and mercury vapor, as well as over 100 well-known lighting gels
- FX mode for popular effects such as candle, fire, TV, police, lightning, paparazzi, pulse, and scroll
- Full-range onboard and DMX dimming
- DMX wireless link
Kino Flo KinoGrip MTP-KG41 Mount with 3/8" Pin
The KinoGrip MTP-KG41 Mount with 3/8" Pin from Kino Flo is a twist-on ball and socket mount with a 3/8" pin for attachment to a grip head. The mount has an integrated handle should you wish to hand hold the light fixture.
Kino Flo FreeStyle 140 LED DMX Controller for FreeStyle T44 Bulbs, (120 VAC Cord)
This Kino Flo FreeStyle 140 LED DMX Controller for FreeStyle T44 Bulbs comes with a power cord for running on 120 VAC while controlling and powering up to four T44 LED tubes. The controller features four modes that provide near total control of the output of the LED tubes (LED tubes not included). In white mode, the unit drives LED tubes output light with a color temperature range between 2700 to 6500K. It also enables dimming and green/magenta adjustment. Gels/Hue expands the color temperature range to 2500 to 9900K while providing access to background keying presets and over 100 lighting gel looks.
RGB mode provides access to the individual red, green, and blue LED luminaries for precise control. FX Mode provides customizable presets. The integrated display screen shows dim, Kelvin, green/magenta shift, and the DMX Channel. Four built-in buttons default to four Kelvin presets, but you can customize the settings of the buttons. The built-in control knob lets you set dimming, Kelvin, green/magenta levels and DMX address. The controller supports both wired and wireless DMX, and it accepts worldwide power inputs as well as 18 to 36 VDC.
Menus
- White: dimming, tunable Kelvin range from 2700K tungsten to 6500K daylight; Green/Magenta controls
- Gels/Hue: extended Kelvin color range from 2500-9900K and provides access to Kino Flo presets such as blue & green screen, sodium vapor, mercury vapor as well as over 100 well-known lighting gels
- RGB: provides access to individual red, green, and blue control. Works with Apps with predetermined RGB presets or color wheels
- FX: custom presets like Candle, Fire, TV, Police, Lightning, Paparazzi, Pulse, and Scroll with control parameters that can be altered. For example, Lightning effect has a "Storm" and "Frankenstein" preset, but can change the Rate to provide additional variation
Kino Flo Extension Cable 150 for Select LED System (25')
The 25' Extension Cable 150 for Select LED System from Kino Flo provides extra distance between the Select LED head and its ballast. Up to 2 extensions can be joined for a total of 50'.
Kino Flo LED Tube For Freestyle T44 Fixture (4') Specs
Length | 4.0' / 1.2 m |
CRI | 95 |
Color Temperature |
2500 to 9900K |
Kino Flo FreeStyle T42 LED Fixture Specs
Light Fixture
Item Type | 1 x LED Light Tube/Wand |
Photometrics | 150 fc / 1620 Lux at 3.3' / 1 m* 43 fc / 465 Lux at 6.6' / 2 m 19 fc / 215 Lux at 9.8' / 3 m *Standardized Measurement Supplied by the Manufacturer |
Color Temperature | 2500 to 9900K |
Dimming | Yes, Built-In Dimmer 1 to 100% |
Front Accessory Mount | Proprietary |
Connectivity
Wireless Remote Control Type | Unspecified Type |
Power & I/O
Power Source | AC Power (Cable Not Included) Power Supply/Controller (Not Included) |
AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Inline Switch | No |
Power Pass-Thru | No |
Mounting
Fixture Mounting | 1 x Lollipop Receiver |
Kino Flo KinoGrip MTP-KG41 Mount With 3/8" Pin Specs
Diameter | Pin: 0.375' / 9.5 mm |
Kino Flo FreeStyle 140 LED DMX Controller For FreeStyle T44 Bulbs, (120 VAC Cord) Specs
Connections | Power AC Input: IEC Connector DC Input: 3-Pin XLR DMX In & Out: 5-Pin XLR (Male & Female) USB: Mini-B |
Dimming Range | 100 to 1% Brightness |
Power | Voltage AC: 120 to 240 VAC, 50/60 Hz DC: 18 to 36 VDC, 150 W Draw AC: 1.25 A @ 120 VAC DC: 6.25 A @ 24 VDC Fuse 3.15 A/250 V |
Dimensions | 9.5 x 4.5 x 2.5" / 24.13 x 11.43 x 6.35 cm |
Weight | 4.5 lb / 2.04 kg |
