Product Description
Kino Flo Freestyle Mini LED DMX Universal System with Soft Case
Overview
The Freestyle Mini LED DMX Universal System with Soft Case from Kino Flo features the FreeStyle Mini LED Fixture and FreeStyle 120 LED DMX Controller. Also included are the KinoGrip K41 Mount with Baby Receiver, 25' Head Extension Cable, US power cable, 2-pin Euro power cable, and a soft case to protect the components.
Slim and compact in size, the FreeStyle Mini LED Fixture offers the same Color Science LED technology found in all Kino Flo LEDs. The portable and lightweight fixture can fit easily into tight locations or be handheld with the included KinoGrip 41K Mount, which also allows mounting to accessories and light stands with a 5/8" baby pin. Additionally, the back of the fixture comes with a twist-on removable KinoGrip Center Mount, which can be adapted to work with multiple Kino Flo mounting adapters.
The FreeStyle DMX Controller features four individual modes: White, Gels/Hue Color, RGB Color, and FX. The White mode features dimming from 1 to 100% and a tunable range of 2700 to 6500K. In the Gels/Hue Color mode, the range is expanded from 2500 to 9900K. The gel channel also includes Kino Flo presets such as blue and green screen, sodium vapor, and mercury vapor, as well as over 100 well-known lighting gels. RGB Color mode gives individual control of red, green, and blue LEDs, and in FX mode you are provided access to popular effects such as candle, fire, TV, police, lightning, paparazzi, pulse, and scroll.
- Adjustable color temperature from 2500 to 9900K
- 1 to 100% dimming without color shifts
- Flicker-free and quiet operation
- Gel presets include blue and green screen, sodium vapor, and mercury vapor, as well as over 100 well-known lighting gels
- FX mode for popular effects such as candle, fire, TV, police, lightning, paparazzi, pulse, and scroll
- Full-range onboard and DMX dimming
- DMX wireless link
- 25' Head Extension Cable for versatility in mounting and controlling fixture in hard-to-reach locations
- Hand or Stand Mountable
- Padded case with zippered enclosure and shoulder strap
Key Features
- Mini LED Panel with Louver
- DMX Controller
- Gel Presets and FX Mode
- 2500-9900K Adjustable Color Temperature
- KinoGrip K41 Mount with Baby Receiver
- 25' Head Extension Cable
- Multi-Voltage: 100-240 VAC
Specs
Light Fixture
Item Type | 1 x LED Light Panel |
Included Filters | Soft Diffusion |
Included Storage Case | 1 x Case |
Photometrics | 76 fc / 828 Lux at 3.3' / 1 m* 20 fc / 219 Lux at 6.6' / 2 m 9 fc / 99 Lux at 9.8' / 3 m *Standardized Measurement Supplied by the Manufacturer |
Color Temperature | 2500 to 9900K |
Dimming | Yes, Built-In Dimmer 1 to 100% |
Front Accessory Mount | Proprietary |
Power & I/O
Power Source | AC Power (Cable Included) Power Supply/Controller (Included) DC Input (Cable Not Included) Battery (Not Included) |
Inputs/Outputs | Light Fixture 1 x Built-In Cable with Proprietary Power Input Power Supply/Controller 1 x IEC Power Input 1 x XLR 3-Pin Power Input |
AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
DC Input Power | 18 to 36 VDC |
Included Adapter / Cable | Yes |
Inline Switch | No |
Power Pass-Thru | No |
Power Consumption | 100 W |
Mounting
Fixture Mounting | 1 x 5/8" Receiver (Via Hardware) |
Dimensions | 15 x 7.5 x 3" / 38.1 x 19.1 x 7.6 cm (Fixture) |
Weight | 3.5 lb / 1.59 kg |
