Product Description

Johnson Systems PWS-20P-RETRO Presidor Wall Station - 20 Presets

Presidor Wall Stations (PWS) represent the next step in Architainment Lighting Controls. Intuitive operation is coupled with state-of-the-art capacitive touch technology permitting powerful distributed lighting controls for single or multi-room environments. Attractive 1 gang “Patent Pending” design is supported by color-matched adapter plates up to 7 gang and surface mount back boxes. Up to 70 presets on one universe of DMX512, a PWS can operate as either a DMX console or a DMX snapshot/playback device. Flexible and programmable auxiliary contact input and real-time scheduling allow for a myriad of interface possibilities with Building Management and Show Control systems. Wiring topology is fast, simple and inexpensive with standard Cat5/5e or Cat6 cabling using standard RJ-45 connectors. Daisy-chain up to 15 stations per room for multi-room environments of up to 25 rooms when used with a Presidor Room Linker/Combiner (PRLC).

Features

• Attractive “Patent Pending” screwless design is ergonomic and sealed to dust.
• 70 presets on one universe of 512DMX channels. Operates as either a DMX console or a DMX snapshot/playback device.
• State-of-the-art high speed, low power “green” processor and ancillary circuitry with a power consumption < ¼ Watt.
• Bluetooth ready for remote preset activation via cell phone.
• Dual integrated light pipes allow for both automatic proximity sense and ambient light sense.
• Embedded programming with alphanumeric preset labeling.
• Intuitive navigation allows ease of operation. Unique interactive real-time functionality including manually activated digital sliders.
• Password-protected access for customized security.
• Up to 15 daisy-chained stations per room/zone power and data inclusive over Cat5/5e/6 or 3-Pair cable.
• Up to 25 rooms/zones per DMX universe with the use of Presidor Room Linker/Combiner (PRLC).
• Small compact size permits installation in standard, readily available single gang electrical back boxes.
• Available in white or black with optional colormatched adapter plates and surface mount back boxes allow for virtually unlimited retrofit possibilities.

Specs

• Voltage: 5 – 48VDC operational range. 48VDC when used with PRLC-4 Room Linker/Combiner (48VDC supplied by PRLC-4).
• Power Consumption: < 1 Watt per station during operation and < ¼ Watt during standby mode.
• Cabling: RS485 Cat5/5e/6 cable (RJ-45) or retrofit into existing Belden #9773 or equivalent (terminal block), 300m max. (1000’).
• Operating Conditions: 0°C to 40°C (32°F to 105°F); 10-90% relative humidity, non-condensing.
