Presidor™ Lighting Panels permit a selection of both LED dimmer and relays in the same enclosure for highly efficient and cost-effective installations. DMX input with optional DIN rail node allows for wide application in two panel sizes. Small panels are available in either 8 or 12 channels while the large panel supports up the 24 channels. The large panel also has an optional splitter panel with local 3 pole 40 Amp disconnect breaker for larger installations. Panels can be ordered custom built with the modules of choice pre-installed at the factory in the chosen order. Module choices are quad dimmer, quad relay or dual relay. Intelligent dimmers are state-of-the-art reverse phase controlled rated at 600W and will dim both LED and incandescent loads over a full range of dimming (1-100% DMX). Air-gap relays are triggered ON/OFF at selectable DMX% thresholds from 10-90%. 0-10VDC analog outputs can be programmed as source or sink to permit direct drive of analog ballasts. Sensing protection on all circuits includes overload, short-circuit, temperature, over-voltage, inductive load and more. Both LED indication and real time error reporting back to the command control provide advanced feature reporting normally only found in very expensive dimmers. The Presidor™ Command Controller provides a full color, capacitive touch GUI for ease of set up and automatic error reporting. Intuitive operation and smart capabilities make these panels unique.
