Product Description
Johnson Systems DMX-2PM-DIN 2-Port Merger
JSI’s DMX 2-PORT MERGERS combine two DMX512 data lines into one DMX512 universe providing cost-effective DMX input expansion for temporary and hardwired installations. Input DMX data streams can be combined in a “Highest Take Precedence” (HTP) or selected as “Priority” for backup source or automatic lockout applications. Multiple units can be cascaded together for larger installations.
Available in a choice of portable small enclosure or DIN rail for cabinet mounting, these mergers represent the highest quality for the money available.
Please note: Power Supply is not included and must be purchased separately. The Johnson Systems PS-MINI-15 is the compatible power supply.
Features
- Two opto-isolated DMX512 inputs, one opto-isolated DMX512 output.
- All inputs and outputs employ fast acting, “self-healing” fuse protection.
- Inputs can be selected for “Priority” or “Merge” operation.
- Selectable speed choice of “Fast” or “Slow” DMX.
- Power and data receive LED indicators.
- Unique power saving standby (idle) mode reduces power consumption to less than 1 Watt, a “green” power management product.
Specs
Power Supply Requirements
- DMX-2PM = 12VDC (adapter included)
- DMX-2PM-DIN (installation version) = 12VDC at 150mA
Environment
- Temperature Range: 23°F (-5°C) to 104°F (40°C) ambient
- Humidity Range: 0% to 90% non-condensing
Isolation
- 2000 Vrms minimum per DMX input
- Auto-resetting 240V polyswitch fusing of all DMX inputs and output
Physical
- DMX-2PM = 4" x 3" x 1.75" (10 cm x 7.6 cm x 4.4 cm)
- DMX-2PM-DIN = 4" x 3.5" x 2" (10 cm x 8.9 cm x 5 cm)
Weight
- DMX-2PM = 0.48 lbs. (217g)
- DMX-2PM-DIN = 0.21 lbs. (94g)
Material
- DMX-2PM = Aluminum extrusion with aluminum end plates. Black anodized.
- DMX-2PM-DIN = Plastic DIN rail extrusion. Black.
