Control CRV
High Design Loudspeaker with 70V/100V Transformer. Weather Resistance. Unique, contemporary, curved design. Dual 100 mm (4 in) woofers provide superb sound quality. Combinable into half-round or full 360° round arc clusters.
High Design Loudspeaker with 70V/100V Transformer. Weather Resistance. Unique, contemporary, curved design. Dual 100 mm (4 in) woofers provide superb sound quality. Combinable into half-round or full 360° round arc clusters.
Frequency Range | 80 Hz – 20 kHz |
Power Capacity | 75 W continuous pink noise (300 W peak) |
Transformer | Selectable 70V/100V or low impedance |
Usability | Indoor/outdoor capable |
Colors | Black, or White (-WH) |
Sensitivity | 89 dB, 1W@1m |
Maximum SPL (1m) | 108 dB continuous average long-term (peaks of 114 dB) |
Coverage Angle | 105°H x80°V |
Impedance | 4 Ohms |
Transformer Taps | 30 W, 15 W, 7.5 W (plus 3.8 W @ 70 V only), plus Thru |
Drivers | LF Driver: Dual 4" (100 mm) HF Driver: 3/4" (19 mm) |
Input Connectors | Screw-down terminal strip |
Grille | Zinc-plated steel |
Mounting Hardware | Included wall-mount bracket. Optional pole-mount accessory. |
Outdoor Capability | IP-34 rating. Exceeds MilSpec 810 for humidity, salt spray, temperature & UV. Passes Mil-Std-202F for salt spray |
Included Accessories | Corner/wall-mount bracket with cap, screws, and trim covers |
Optional Accessories | Pole-Mount Bracket for 4-speaker 360° hanging pendant cluster |
