Product Description
Interactive Technologies IT-SP8D DIN Rail Splitter
DMX Splitters are used to create multiple independent branches of a DMX signal and/or extend the usable distance of each branch. Our DIN Rail mounted DMX Splitter, the IT-SP8D, is designed for use in permanent installations. Each of the 8 output ports on this model can generate an independently protected DMX signal capable of traveling up to 1,800 feet (550 meters). The IT-SP8D includes a DMX Pass-Thru port for cascading DMX through multiple splitters and provides a built-in DMX Termination switch.
Features
- Compact DIN Rail housing
- Pluggable terminal blocks for each connection
- Rugged anodized aluminum cover plate
Specs
| Power | 6-30VDC, 2-position removable terminal block |
| DMX Input | 3-position removable terminal block |
| DMX Pass-Thru | 3-position removable terminal block |
| DMX Output | (8x) 3-position removable terminal block |
| DMX Termination | Yes, On/Off Switch |
| DMX Polarity Inversion | Not needed as polarity can be inverted at each terminal block |
| Width | 4.17" (106 mm) |
| Length | 4.82" (122 mm)
|
| Height | 2.00" (51 mm) with DIN Rail brackets
1.22" (31 mm) without DIN Rail brackets |
| Weight | 7.8 oz. (222 g) |
| Operating Temperature | -40° to 158° F (-40° to 70° C) |
| Storage Temperature | -40° to 176° F (-40° to 80°C) |
| Relative Humidity | 5% to 95% noncondensing |
| Altitude | 10,000 feet maximum |
| Included Items | IT-SP8D Splitter Unit
Removable DIN Rail brackets
Getting Started Documentation |
Other Details
Interactive Technologies, Inc. (“Interactive”) warrants this Product (including any accessories) against defects in material or
workmanship under normal use and service for a period of 2 years from the date of purchase to the original owner when
purchased from an authorized Interactive dealer. Proof of purchase may be required to obtain warranty coverage.
This warranty provides only the benefits specified and does not cover defects or repairs needed as a result of acts beyond the
control of Interactive including but not limited to: abuse, damage by accident/negligence, modification, alteration, improper
use, unauthorized servicing, tampering, or failure to operate in accordance with the procedures outlined in the owner’s
manual; nor for acts of God such as flooding, lightning, tornadoes, etc.
If your Interactive product requires service during the warranty period, Interactive will repair or replace, at its option, defective
materials provided you have identified yourself as the original owner of the product to Interactive or any authorized Interactive
dealer. Transportation charges to and from an authorized dealer or the Interactive factory for repair shall be the responsibility
of the owner.
All products returned to Interactive must have factory authorization prior to shipping.
INTERACTIVE’S LIABILITY FOR ANY DEFECTIVE PRODUCT IS LIMITED TO REPAIR OR REPLACEMENT OF
THE PRODUCT, AT OUR OPTION. IF WE ELECT TO REPLACE THE PRODUCT, THE REPLACEMENT MAY BE A
RECONDITIONED UNIT. INTERACTIVE SHALL NOT BE LIABLE FOR DAMAGES BASED ON INCONVENIENCE, LOSS
OF USE, DAMAGE TO ANY OTHER EQUIPMENT, OR OTHER ITEMS AT THE SITE OF USE, OR ANY OTHER DAMAGES
WHETHER INCIDENTAL, CONSEQUENTIAL, OR OTHERWISE. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW THE EXCLUSION OR LIMITATION OR INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
This Warranty applies to the following Product Families and associated Accessories:
CueServer™, CueServer 2™, CueStation Insite™, CueStation Mystique™, CueStation Ultra™, CueTouch™, IT-DMX Interfaces,
MicroTech DMX™, RadioDMX™, SceneStation™, and Sidewinder DMX™.
