ILC LightSync Switch Vue Manual
This manual includes enclosure dimensions, mounting plate/mud ring dimensions details, bezel face plate dimensions,remote transformer installation, switch vue hardware installation, cat5 and power wiring details,installation instructions, manual conventions, installing ILC switch vue software, creating switch vue screens, starting ILC switch vue pro program, ILC switch vue pro menu bar, other screen features and controls, screen programming objects types, starting a new file and saving it to hard drive, adding screens, adding navigation touch areas, adding relay group or presets status objects, incrementing and decrementing a variable, using variables to control relays groups or presets, adding relay control touch areas, adding group control touch areas, adding a preset control touch area, programming a variable to control to work with another variable, setting up the switch vue on the network, downloading programming, upload the password and show the last touch point, calibrating the touch control areas.
The ILC LightSync SwitchVUE touch activated LCD graphical control station is designed to interface ILC LightMaster line of lighting control panels. The SwitchVUE is able to provide real time status and control of any relay, group or preset in any panel on a Standard or Extended network. With the use of the ILC LightMaster SwitchVUE Pro software you are able to configure and program the SwitchVUE interfaces. With the use of Windows Paint program or other graphics program you can create the custom background screens that depict your spaces in your facility, or use the standard screens that are provided with the software install disk. Up to 30 screens can be loaded into a standard configured unit or up to 126 with factory memory upgrades. Each screen is able to store up to 32 control objects which will give you status and control of your relays, groups and presets in your LightMaster network system.
