Product Description
Hollyland HL-Solidcom M1-4B-DH Solidcom M1 Double-Ear Headset-4B
Full-Duplex Wireless Intercom Solution
Team Communication to the Next Level
With major technical breakthrough, Hollyland is proud to present you a whole new series of full-duplex wireless intercom — Solidcom. As the first member of this series, the Solidcom M1 is your go-to choice for small- and medium-sized events with a capacity from 100 to 1000 guests, including church events, electronic field productions, exhibitions, concerts, and more.
Industry-First Solution to Power Up to 1,300ft (400m) Communication Range
For the first time in the industry, an integrated panel antenna is inserted into the base station. Besides, the Solidcom M1 is also equipped with a pair of external FRP antennas. Combining these 2 antenna options, the Solidcom M1 significantly improves on-site work efficiency and flexibility, and prolongs transmission range to a great extent.
Built-in Panel Antenna
With a 1,300ft (400m) transmission range fronting the panel and an extra 160ft (50m) range at the back, the built-in panel antenna is perfect for real-time two-way communication in unobstructed venues, such as church events and concerts. Open the box, power up the devices, and there you go! The Solidcom M1 is ready for its mission!
External FRP Antennas (Coming in One Pair)
The external FRP antennas are endowed with reliable transmission in a 360° radius range of around 985ft (300m), ideal for large-scale events including sports events, exhibitions, etc.
Enhanced Audio Quality Let Your Voice Be Heard Crisp and Loud
With an all-round upgrade, the Solidcom M1 guarantees smooth and clear group communication no matter how loud and complicated the background noise is.
Intuitive Grouping at a Single Tap
Setting up groups with the Solidcom M1 is an intuitive experience. It's as easy as selecting the numbers of specific beltpacks and making them a group. Either through the base station, Solidcom app, or webpage, a group can be created and managed in seconds.
Up to 3-Group Team Communication
The system supports up to 3-group team talk. You can flexibly allocate the beltpacks to team members such as lighting crew, camera crew, PAs, etc.
Multi-Device Cascaded Connection for Hassle-free Group Communication
Fitted with 4 different interfaces — 2W (XLR connector), 4W (RJ45), POE/LAN power supply, and cascading interfaces, the base station can be cascaded with multiple sets of different audio equipment only by connecting with a standard network cable or an XLR cable.
Compatible Product List
| Clear-Com Wired/Wireless Intercom System | |
| Hanson Wired Intercom System | |
| Altair Wireless Intercom System | |
| Datavideo Intercom System |
Each set of Solidcom M1 is equipped with 8 beltpacks. Simultaneous group calls for 16 people in 3 groups are made possible with 2 cascaded sets, with a standard network cable of 328ft (100m) for cascading, sufficient for staff dispatching of most events.
Out-of-Box Convenience
The beltpacks are paired by factory by default and are good to use out of the box. In the event of cross-area collaboration where changing or adding beltpacks is needed, you only need to connect the beltpacks to the base station via a USB to Type-C cable to pair and group the beltpacks.
A Plethora of Choices for Your Ears
The Solidcom M1 comes with professional LEMO headsets whose microphones can be switched off or on by putting down the microphone boom or vice versa. The headset is also featured with the sidetone function which allows you to hear your voice even with the microphone on and then adjust the voice volume in time.
Say No to Low-Battery Anxiety
Each beltpack is equipped with 2 removable Li-ion batteries which can be charged independently and fully charged in only 2.5 hours. With a 6-hour runtime for each battery, the beltpack will never be out of power when you are using the two batteries in turn.
Hollyland Solidcom M1
The Solidcom M1 is your go-to choice for small- and medium-sized events with a capacity from 100 to 1000 guests, including church events, electronic field productions, exhibitions, concerts, etc.
Specifications
Base Station
Interface: POE Interface (RJ45)
Power Supply Interface (RJ45)
4-Wire Audio Interface
USB Interface
2-Wire Audio Interface
Power Supply: POE Power Supply
NP-F Battery
Frequency Response; 200Hz to 7kHz
Signal-to-Noise Ratio: >50dB
Distortion: <1%
Transmission Range: 1,300ft (400m) LOS
Frequency Band: 1.9GHz
Modulation Mode: GFSK
TX Power: Maximum 21dBm
RX Sensitivity: ≤–93dBm
Frequency Bandwidth: 1.728MHz
Power Consumption: <3W
Dimensions: (L x W x H): 255.5mm x 180.4mm x 48.5mm (10" x 7.1" x 1.9")
Weight: About 1560g (55oz)
Temperature Range: 0 to 45℃ (Working Status)
–20 to 60℃ (Storage Status)
Beltpack
Interface: 3.5mm Headset Interface
LEMO Headset Interface
USB-C Interface
Power Supply: 1500mAh Lithium Polymer Battery
Frequency Response: 200Hz to 7kHz
Signal-to-Noise Ratio: >50dB
Distortion: <1%
Transmission Range: 1,300ft (400m) LOS
Frequency Band: 1.9GHz
Modulation Mode: GFSK
TX Power: Maximum 21dBm
RX Sensitivity: ≤–93dBm
Frequency Bandwidth: 1.728MHz
Power Consumption: <0.6W
Dimensions: (L x W x H): 105mm x 65mm x 22.4mm (4.1" x 2.5" x 0.9")
Weight: About 200g (7.05oz)
Temperature Range: 0 to 45℃ (Working Status)
–20 to 60℃ (Storage Status)
