Product Description
High End Systems 61040064 Hoglet 4 Consolette
Our most compact Hog yet! The Hoglet 4 is a compact wing, designed for tight spaces and small productions such as clubs, churches and small concert venues. Combine the Hoglet 4 with Hog 4 PC and you are ready to rock!
Even a seasoned Hog programmer will feel right at home on the Hoglet 4, as it has a programming surface similar to its larger brothers. Combine Hoglet 4, Hog 4 PC and a touchscreen and you have a proper, full-fledged lighting console with four DMX ports and four encoders built in.
Hoglet 4 is also a great companion to the Rack Hog 4, as it makes operating a show in a confined space or programming fixed-installations a breeze.
FEATURES
- USB connection to Rack Hog 4, Hog 4 PC, or any Hog 4 family console
- 10 manual playback faders
- Four expanded-wheelset encoders
- 12 user-assignable function keys
- Kensington security slot
- One dimmable white desk light included
- Dust cover included
- Custom road case available
- Compliance: ETL, CETL, CE
CONNECTIVITY
- Built-in DMX Super Widget
- Local DMX-512 outputs: 4x Neutrik 5-pin XLR
- USB 2.0 ports: 2 rear
ELECTRICAL
- External PSU input: 100-250VAC, 50/60Hz, max 25W
- External PSU output: 12VDC 2.5A/25W
WEIGHTS AND DIMENSIONS
- Width: 603mm / 23.8"
- Depth: 314mm / 12.4"
- Height: 67mm / 2.6"
- Weight: 3.9kg / 8.7lb
ADDITIONAL ACCESSORIES:
- 61040064 Hoglet 4 programming wing
- 61080011 Hoglet 4 programming wing dust cover, replacement
- A2080004 Hog white desk light, replacement
- 64070016 Hoglet 4 programming wing road case
- 74040011 USB DMX Widget
- 74040008 USB DMX Super Widget
- 62040005 USB DMX Super Duper Widget
- 7404009 USB MIDI/LTC Widget
SPECIFICATION • USB connection to Rack Hog 4, Hog 4 PC, or any Hog 4 family console • Full programming keypad • Four expanded-wheelset encoders • 12 user-assignable function keys • 10 non-motorized playback masters with go, halt, choose and flash keys • Master column and paging button • 4 Neutrik XLR-5 DMX outputs
INTERFACES AND ACCESSORIES • Built-in DMX Super Widget • Local DMX-512 outputs: 4x Neutrik 5-pin XLR • Expandable DMX-512 outputs via USB DMX Widgets • USB 2.0 ports: 2 rear
ELECTRICAL AND ENVIRONMENTAL • ETL, CETL and CE compliance • External PSU input: 100-250VAC, 50/60Hz, max 25W • External PSU output: 12VDC 2.5A/25W
