Product Description
Heil Sound RC-35 CHROME Replacement Wireless Capsule - Chrome-Plated
The Heil RC 35 is a replacement microphone capsule for wireless transmitters, using the same internal elements as the PR 35. The RC 35 gives you all the great articulation and high rejection of side and rear noise, along with other benefits of the PR 35.
The RC 35 lets you upgrade your transmitter (of most popular brands*) to the PR 35 sound and reliability with wireless freedom and your choice of three looks. The smoother, flatter response with very high side and 180-degree rejection will make it worth replacing your current brand with the RC 35. Turning your wireless transmitter into a world-class microphone is just a few screw turns away.
The RC 35 capsule is available in black, gold plate, or chrome plate. The gold plate version is by special order only.
The RC 35 capsule is compatible with all Lectrosonics, and Line 6 models that have removable capsules. It is compatible with most Shure Wireless with removable capsules, except it will not work with the ULX systems. It is also compatible with the AudixH60 utilizing the included spacer ring.
Features
- Increase vocal articulation with maximized rear rejection and lower handling noise
- 1.5" large dynamic element of the PR 35
- Interchangeable with 31.3mm/pitch 1.0mm
- 40Hz - 18kHz frequency response
- Cardioid polar pattern, uniform front to back discrimination
Specs
- Product: RC 35 CHROME
- Thread: 31.3mm/pitch
- 1.0mm threading
- (1.25” x 28 thread pitch)
- Element Type: Dynamic
- Frequency Response: 40 Hz – 18 kHz
- Polar Pattern: Super Cardioid
- Rear Rejection @ 180 degrees off axis: -35 dB
- Impedance: 370 ohms balanced
- Output Level: -52 dB @ 1 kHz
- Weight: 5.5 oz
- Max SPL: 140 dB
