Product Description

Hear Technologies MBR Mix Back Remote

Overview

The Hear Technologies Mix Back Remote is designed for use with Mix Back Monitor Mixer only. With the Hear Technologies Mix Back Remote Control, the talkback mic preamp is assignable to stereo masters 1 and 2, mono outputs 1 - 12, and the balanced intercom/slate output. It connects up to 500 feet with a standard CAT5e cable. The talkback (remote COM) balanced output acts as an intercom for communicating with the front of house engineer or to the talent when used in a studio. The remote COM button also activates a relay for lighting beacons or virtually any function needing a set of dry contacts. The Hear Technologies Mix Back Remote features a built-in threaded Mic adapter for easy attachment to microphone and music stands using Hear Technologies' MSA adapter or may be directly mounted to a mic stand.

Features

• Remote Output: The Hear Technologies Mix Back Remote is connected to the Mix Back using standard CAT5e cable. (wired 1 to 1)
• Switches 1-12: Routes the talkback microphone to the corresponding Mix Back master sections. Very useful for talking to a particular "more me" output. Talkback is useful for live and studio personal cue.
• ST1/ST2: When selecting ST1 and/or ST2 switches, one can talk to everyone listening to those corresponding stereo mixes.
• COM: The COM button turns on the talkback balanced output connector on the rear panel and closes the talkback relay (for light beacons, dimming module for control rooms, the Talk Back 600 MV logic input, etc.).

Includes

• 1 x Hear Technologies Mix Back Remote
