Product Description
HazeBase HB-0834 PICCOLA 200W Water-Based Battery Fog Machine
Overview
The Piccola is a battery-operated smoke machine for use both as a fog effect in the entertainment area, as well as for flow tests or leak detection. It only needs the shortest heating times (1 sec.) And also has a compact housing with low weight (2.6kg).
The Piccola only takes energy from the battery when a fogging process is started. This process runs according to the following scheme.
- 1) Heating up (approx. 1 second)
- 2) Fluid pump delivers and fog is generated
- 3) Follow-up time of 10 seconds (the heating is still active while the pump is switched off)
Features
- battery-powered fog machine
- 1 second heating time
- DMX RDM
- Fog density flexibly adjustable
Specifications
| Operating principle | Vaporizer fog machine, directly heated, battery operated |
| Connection data | 200W, 12V DC |
| Heating time | 1 second |
| Fluid tank | 250ml |
| Fog density | Adjustable in 25%, 50%, 75%, 100%, Single Shot |
| Battery life |
30 min at 25% 10 min at 50% 6 min at 75% 4 min at 100% |
| Fluid consumption |
1.5 ml/min at 25% 3.0 ml/min at 50% 4.5 ml/min at 75% 6.0 ml/min at 100% |
| Supported protocols | DMX-512, RDM |
| Battery | Lead gel battery, 12V/3.4Ah |
| Charger | 15W/18V DC, wide range input (90-264V) with exchangeable primary adapters |
| Supported fluids | base*B |
| Optional accessories | Radio remote control, cable remote control via 5-pin XLR, hose cover, 5-pin XLR cable whip |
| Weight | 2,6kg |
| Dimensions (LxWxH) | 203 x 79 x 163 mm (incl. battery and tank holder) |
