Product Description

German Light Products SET 610 KNV Line Tourpack with Stackable Case

Overview

GLP KNV Line Tourpack With Stackable Case

Includes: 10 x KNV Line; 2 x KNV PSU; 10 x KNV Line bracket; 10 x 5035-B coupler; 2 x omega; stacking case.

German Light Products KNV Line

German Light Products' KNV Line brings a whole new dynamic to entertainment lighting with it's five 30-watt white LED pixels, each encircled by 16 RGB LEDs, in a linear format. Groundbreaking in both design and functionality, the KNV system comes in four variants, the KNV Line, KNV Dot, KNV Arc and KNV Cube, which work as independent units or combine seamlessly together, all in IP54 outdoor rated housing. These multi functional fixtures are equally happy being used as pixel mapped surfaces, strobes, blinders, washlights, and more, all without ever thermalling out or reducing output level at full. The KNV Line's linear body features 5 LED pixels that have the ability to join seamlessly with the KNV Cube and KNV Arc. Whether adding a small sliver of an extension, creating a juxtaposed design structure, or a extending a simple linear length, the fixture brings great flexibility to any lighting and set design. With independent control over both the white LEDs and the RGB LEDs, create a vast array of effects using the full color pallet plus the added punch when you need it. Each fixture can also be pixel mapped for fluid integration with other visual elements. With incredible output for its small, physical size, each KNV Line is capable of producing more than 11,000 lumens. The KNV Line is powered from an external power supply reducing the size and weight and increasing their ability to be placed in the tiniest, tucked away locations. Daisy chain using ODS 6-pin cables that carry both power and data, up to the maximum pixel count of 25 pixels with any combination of KNV Dot or KNV Line on each power supply unit. Able to be hung individually, or combined together through a fast quick locking system to create larger shapes and forms, the KNV system from GLP is a new mighty powerhouse. A full range of PWM settings ensure flicker free operation in any setting, along with the option to operate the LEDs in either 8 or 16 bit.

Features

• Powerful strobe/color effect lighting fixture
• KNV variants that can be interlocked and combined, giving enormous creative possibilities
• Frameless design allows units to be seamlessly coupled together
• Combines powerful white light output from 30-watt cool white LEDs with bright color output
• 80 high-quality RGB LEDs in circles around the 5 white LEDs
• Total luminous flux can exceed 11,000 lumens per module
• Pixel-mapping through any standard controller
• White and color output can be controlled separately or combined for stunning effects
• The powerful internal multilayer FX engine can create complex dynamic effects quickly with no need for a separate pixel-mapping media server
• Use indoors in permanent and temporary installations
• IP54 rating; can also be used outdoors in temporary installations with precautions for immersion in water and direct sunlight
• Can be mounted in any orientation on a level surface or suspended
• Four mounting points with M3 threaded holes are provided on the front for mounting GLP optical accessories
• For ease of installation, power and data can be daisy-chained

Specifications

• Light Source: 5 hyper bright 30 watt, white LEDs, each surrounded by 16 RGB LEDs; 11,000 lm
• Control:
  • Protocols:
    • DMX 512
    • ArtNet
    • sACN
  • Mode (TBC):
    • 10
    • 17
    • 37
    • 83
    • 29
    • 102
    • 202
  • PWM: Variable up to 38khz
• Effects:
  • 16 bit RGBW color
  • 16 bit electronic dimming
  • Variable strobe:
    • Intensity
    • Flash rate
    • Flash duration
  • 3 layer FX engine
• Connectors: ODS 6 pin in and thru
• Power:
  • External KNV PSU (sold separately)
    • Connectors:
      • Power: Neutrik True1 input and output
      • Data: Neutrik Ethercon input and output
    • Max fixture count: 5 KNV Line fixtures
• Operating Conditions:
  • IP rating: IP54
  • Maximum ambient temperature: 115°F (45°C)
• Mounting Options:
  • Floor stand
  • Hanging bracket
• Dimensions (LxWxH): 6.5″ x 9.84″ x 1.97″ (16.5 x 25 x 5 cm)
• Net Weight: 3.97 lbs (1.8 kg)
