Product Description
German Light Products Impression X4 Theatre Version with RGBY LED
Overview
German Light Products' impression X4 is a high-powered LED moving head fixture featuring seven individually-controllable 15 watt RGBY LEDs. The 7:1 zoom ratio offers the flexibility of a tight beam from 7° all the way to a smooth edged wash of up to 50°. Control the X4 S via DMX and a yoke mounted LCD display, plus power over Neutrik Powercon in and thru connectors.
Features
- Motorized zoom system with 7° to 50° beam angle
- 15W Osram high powered quad LEDs
- High efficiency collimator cluster for maximum light output
- Macro operation of individual lenses
- Very quiet temperature controlled ventilation
- Internal color presets, and variable color temperature control from 2700K-10000K
- Back lit graphic LCD menu
- Over temperature protection
- Color calibration feature
- 8 or 16 bit resolution
- Position feedback
- Continuous dimmer 0-100%
- Variable speed strobe of 1-25 Hz.
- Random strobe effect
- Pulse effects
- High precision 3 phase stepping motor control
Specifications
- Optical System
- Light Source: 7 Osram high powered RGBY LEDs
- Rated life time: 50,000 hours
- Movement
- Motorized zoom: 7° to 50°
- Resolution: 8 or 16 bit
- Position feedback: yes
- Maximum speed: 660° pan in 2 secs. , 260° tilt in 1 sec.
- Shutter/Dimmer
- Continuous dimmer: 0-100%
- Strobe speed: Variable speed of 1-25 Hz.
- Random strobe effect: yes
- Pulse effects: yes
- Control
- Protocol: DMX 512
- Variable white temperature control: 2700K-10000K
- Over temperature protection: yes
- Display: Back lit graphic LCD menu
- Color calibration: yes
- Power Supply
- Power consumption: 150 VA (Watt)
- Power input: auto sensing 100-240 V AC, 50-60Hz
- Fuse protection: micro fuse 5 mm x 20 mm, T 2A
- Connectors
- DMX: XLR 5-pin
- Power: Neutrik powercon in and thru
- Operating Conditions
- Maximum ambient temperature: 113°F (45°C)
