Product Description
German Light Products Fusion FS16 Z 1 Meter Batten with 16 x 20W RGBW, 8 to 40 Degree Motorized Zoom
Overview
The FUSION Stick FS16 Z has a motorized zoom between 8° and 40° beam angle. It is still the same size and dimensions as the FUSION Stick FS20, so all diffusors, including asymmetrical options, and accessories are available to use.
The Halo Ring is another innovation implemented to increase pixel visibility in TV applications. In all camera angles the single pixels are visible at any zoom position due to the ring around the front lens and still create stunning narrow beams.
The FUSION Stick FS16 Z features an IP rating of 65, allowing for full outdoor use regardless of poor weather conditions. To that end the Stick features a fanless design, which not only ensures the IP65 rating, but also enables silent operation for sound sensitive environments such as theaters or television.
The direct vertical hanging and standing are one of the key features to create stunning effects with less rigging effort.
No matter the application, the FUSION Stick FS16 Z is the right choice.
Specifications
Light source
- Type: RGBW
- Number: 16
- Light source power: 20 W
- Light source lifetime: 20,000 h
- CCT: 6,000 K
- CRI (Ra): 70+
- TLCI: 42
- TM-30 Rf: 97
- TM-30 Rg: 62
Optical System
- Light output: 5,890 lm
- min. Zoom: 10° beam angle
- max. zoom: 41° beam angle
- Control & Programming
- DMX channels: 6, 14, 33, 79
Protocol(s)
- DMX (USITT DMX512-A)
- RDM (ANSI/ESTA E1.20)
- Setting and addressing: OLED display, 4 button menu navigation, DMX, RDM, IR remote control
- Software Update: DMX link
- High-Res Channels: Dimmer
- Dimmer curves: linear, soft
- Others: Stand Alone 1 captured Scene, 3 Layer Pattern-FX-Engine, IR Sensor for Remote Control
Connections
- Signal connection: XLR 5-pin
- Power connection: Neutrik powerCON TRUE1
Electrical specifications
- Power supply: 100 - 240 VAC / 50 - 60Hz
- Power supply: Switching power supply
- power supply cable: 16 A, 1.5 mm², H05VV-F, 1.5 m
- max. power (@ 230V): 450 W
Thermal specifications
- cooling: convection cooling
- max. surface temperature (Ta = 40°C): 90 °C / 194 °F
- max. ambient temperature (Ta max.): 40 °C / 104 °F
- min. Ambient temperature (Ta min.): -10 °C / 14 °F
- Total heat output (calculated, +/-10%): 1,535 BTU/h
Installation
- Mounting: 2 pairs of 1/4 turn fasteners, 2 eyelets for fuse cable
- Orientation: any
- Location: outdoor temporary
- Minimum distance from flammable materials: 0.5 m / 18.7 in
- Minimum distance from illuminated surfaces: 0.5 m / 18.7 in
Structure
- Housing color: Black
- Material: Aluminum
- Protection class: IP 65
- Features: replaceable front screen, IR sensor for remote control: vertical mounting
Dimensions & Weight
- Dimensions (WxDxH): 1023 x 90 x 236mm
- Weight: 13,0 kg
