Product Description
German Light Products 7796 Impression X5 IP Maxx
Overview
The GLP impression X5 IP Maxx delivers an extraordinary luminous flux of up to 24,000 lumens, with an expanded color space, from 37 powerful 40-watt RGBL LEDs.
Equipped with the new iQ.Gamut colour algorithm, the impression X5 IP Maxx generates a clean white point with a CRI 90 / TLCI 90 at 6,500 Kelvin. It also offers the option of quickly switching to other fixed colour temperatures, all of which are precisely calibrated to the color temperature curve, while still offering a color quality of CRI 85 / TLCI 75 even with warm white light of 3,200 Kelvin.
With the new 16:1 zoom mechanism, the impression X5 IP Maxx delivers up to 3.3 Mcd light intensity, a penetrating 3.5° parallel beam and up to 60° homogeneous wash light. The new, circular lens design offers a modern look, while additional fantastic looks can be generated using individual pixel control with pixel mapping and integrated dynamic pattern effects. The impression X5 IP Maxx comes with an extensive feature and effects package, including a virtual color wheel with access to 64 colors from the LEE filter palette, new color quality control, magenta/green correction, a tungsten simulation and effects channel and a 2-layer effect option. Thanks to the IP65 certification, the fixture can be used both indoors and outdoors in any weather. The compact design, with a weight of less than 30 kg, is designed for easily installation in standard pre-rig truss systems. The impression X5 IP Maxx can be controlled via DMX, ArtNet, sACN and LumenRadio CRMX. It also has NFC and the iQ.Mesh module for convenient configuration via the GLP iQ. Service app.
Specifications
Light Source
- Type
-
- RGBL LED
- Light Source Count
- 37
- Light Source Power
-
- 40 W
- Light Source Lifetime
-
- 50,000 h
- LED Refresh Rate
-
- Low, Optimal (Default), High 1, High 2, Max
- CCT
- 6,500 K
- Duv
-
- perfect white point matches with low Duv values
- CRI (Ra)
- 6,500 K: 90 | 3,200 K: 85
- TLCI
- 6,500 K: 90 | 3,200 K: 75
Optical System
- Output
- up to 24,500 lm
- Peak Luminous Intensity
- 3.33 Mcd
- Min. Zoom
-
- 3.5°
- Max. Zoom
-
- 65°
- Zoom Ratio
- 1:19
- Output Lens Diameter
- 380 mm
Effects
- Dimmer
-
- 0 – 100%; 16 bit
- Shutter
-
- Strobe, Pulse, Sparkel, etc.
- Color mixing
-
- RGB
- RGBL
- x;y
- CTC (Color Temperature Control)
-
- 2,500 – 10,000 K
- CQC (Color Quality Control)
-
- High Output (HO)
- High Quality (HQ)
- Desaturation
- Magenta/Green-Shift
-
- yes
- Tungsten Simulation
- 8x linked to fix CCT | 8x relative to Colormix
- Color Wheel
-
- virtual Color wheel, 64 LEE referenced colors
- Pattern Effects
- 50 dynamic pattern macros with special effects
- Pan Movement Angle
- 540° normal (650° extended), 16 Bit Resolution
- Tilt Movement Angle
- 240°, 16 Bit Resolution
- Pan/Tilt Movement Speed
-
- super fast
Control
- DMX channels
- M1: CH22 / M2: CH33 / M3: CH42 / M4: CH141 / M5: CH123 / M6: CH160
- Control Modes
- 6
- Protocol
-
- DMX (USITT DMX512-A)
- RDM (ANSI/ESTA E1.20)
- Art-Net
- sACN
- iQ.Mesh
- optional: Lumenradio CRMX @ FPO
- Setting and addressing
-
- control panel with backlit graphic display
- 4 Button Menu Navigation
- DMX
- RDM
- iQ.Service App
- NFC via iQ.Service App
- Software Update
-
- DMX link
- via DProg
- iQ.Mesh
- Fixture2Fixture Push
- High-Res Channels
-
- Intensity
- Pan
- Tilt
- Colormix
- Performance Modes
-
- fast
- normal (balanced)
- smooth
- Dimming Curves
-
- linear
- soft
- S-Curve
- Fan Modes
-
- regulated
- high
- medium
- low
- off
- Subfixture Mode
-
- Normal
- independent
- White points
- 8,000 K; 5,600 K; 4,200 K; 3,200 K
- Others
-
- Stand Alone 1 captured Scene
- Art-Net/sACN Node
- Data Conversion
- iQ.Mesh
- FPO (Flexible Protocol Option)
- SW Fixture2Fixture Push
Connectors
- Signal connection
-
- XLR 5-Pin
- In/Out
- Neutrik etherCON port A & B (failsafe)
- Power input
-
- Neutrik powerCON TRUE1
- In/Out
Electrical Specifications
- Power input
-
- 100 – 240 VAC / 50 – 60Hz
- Power supply
-
- auto-ranging electronic switch-mode
- Power supply cable
-
- US: 16 A, 14 AWG, UL listed, E304117, SJT, 4.9 ft
- EU: 16 A, 1.5 mm², H05VV-F, 1.5 m
- max. power (@230V)
- 1,500 W
Thermal Specifications
- Cooling
-
- combined convection and forced air
- max. surface temperature (Ta = 40°C)
- 45 °C / 115 °F
- min. ambient temperature (Ta min.)
- 5 °C / 40 °F
- Total heat dissipation (calculated, +/-10%)
- 5,120 BTU/hr
Construction
- Housing Color
-
- Black
- Housing Material
-
- high-impact flame-retardand thermoplastic
- Aluminum
- steel metal plates
- Protection Rating
-
- IP 65
- Construction Features
-
- baseless design
- Tilt-Lock-System
- prepared for external accessories (Egg Crate; Tubus, etc)
Dimensions & Weight
- Height
- 631 mm / 24.8 in
- Width (across yoke)
- 483 mm / 19 in
- Length
- 358 mm / 14.1 in
- Weight
- 30 kg / 77.2 lbs
