Product Description

German Light Products 7685 Impression FR1 60W RGBW LED Moving Head Fixture, 3.5-35° Zoom Range (available in the color of black or white)

Overview

The Impression FR1 is a powerful new moving-head light with one of the most compact automated lighting packages available. Built around a single, high powered 60-Watt RGBW LED, the Impression FR1 offers color mixing across a wide spectrum and can project a punchy, crisp white light with a full range of color temperature control.

Features

• Provides a clean, homogenized output at all angles with a clean beam from center to extreme edge
• Super-fast 3.5° to 35° zoom range with full beam control over short and long-throw distances
• 16-but dimming and 16-bit position control through a range of 540°of pan and 220° of tilt.
• Can perform bi-directional continuous pan rotation at speeds varying from slow and gentle to extremely fast
• Available on-board menu to access a variety of dimmer curve options, full PWM range, and other options. Critical functions also available to control vis the DMX signal
• Base has small footprint and offers power in and thru connectors. It also has rubber feet for floor mounting, threaded sockets for coupler attachments, and built-in safety wire points
• Small and light weight

Specifications

• Light Source
  • 60W RGBW Osram Ostar LED
  • Lifetime: 50,000 hours
  • CRI: 80
  • TLCI: 80
  • TM30-15: 77/106
• Optics
  • Min. Zoom: 3,7°
  • Max. Zoom: 35°
  • Zoom ratio: 10:1
• Movement
  • Pan: 540°
  • Tilt: 220°
  • Resolution: 8-16 bit
  • Position Feedback: Yes
• Control
  • Display: Back lit high contrast graphic LCD menu
  • Protocol: USITT DMX-512
  • DMX channels: 16
  • Cooling: Overheating temperature protection
• Effects
  • Dimmer: 0-100% electronic
  • Shutter: max. 14 Hz electronic
  • Color temperature control: 2,500 K – 10,000 K
  • Internal effects: Color-Presets
  • Color Mixing: RGBW
  • Virtual color wheel match reference: LEE colors
• Connectors
  • Signal: XLR 5-pin in/out
  • Mains power: Neutrik Powercon in/out
• Operating Conditions
  • Mains voltage: 100-240 VAC / 50-60 Hz
  • Power (W @ 230V): 85 W
  • Fuse: 20 mm T 5A
  • Maximum ambient temperature: 115°F (45°C)
  • Orientation: any
  • EEC: E
  • EEI: 1,193
  • Ec (kWh/1,000h): 68
  • IP rating: IP20
• Installation
  • Standing: Rubber feet
  • Hanging (vertical): M10 socket
  • Safety wire attachment: 2 eyelets
• Physical
• Dimensions (LxWxH head vertical): 5.5″ x 7.5″ x 10.4″ (140 x 190 x 264 mm)
• Weight: 8.8 lbs (4 kg)

Select your housing color at the time of order:
