Product Description
Galaxy Audio LV-U3BK Uni-Directional Lav Mic with TA3F connector
UNI LAV/LAPEL MIC: Uni-directional lav/lapel microphone, TA3F connector, 50Hz-19kHz, mic diameter 13mm
This uni-directional lavalier mic comes standard with the ECM, PSE, TRC, DHT, DHX, CTS, & Traveler Lavalier Systems. The LV-U3BK wireless broadcast lavalier microphone is easily concealable and can be wired to work with transmitters made by Galaxy Audio®, Shure®, Sennheiser®, AKG®, and Audio Technica®, as well as most other brands of wireless microphone systems.
- Uni-Directional
- Lapel / Lavalier
SPECIFICATIONS
Sensitivity | -65 ± 4dB (0dB=1V/UBR 1kHz) |
---|---|
Frequency Response | 50Hz - 19kHz |
Output Impedance | 2K Ohms Max. (RL-2.2K Ω) |
Directionality | Uni-directional |
Working Voltage Range | 1 ~ 10V |
Standard Working Voltage | 3V |
Current Consumption | 250UA (Max.) |
Maximum Input Sound Pressure | 110dB SPL |
S/N Ratio | >44dB |
