Product Description
Galaxy Audio JIB/BT8R Bluetooth Receiver Stereo
The JIB/BT8R is a lightweight, compact, portable stereo Bluetooth® receiver that interfaces high quality stereo Bluetooth® audio wirelessly from a smart phone to an active speaker or mixing console. The audio Bluetooth receiver offers a practical, straightforward audio solution for venues that require a quick wireless set up. Additionally, the receiver offers remote pairing capability by connecting to the included euro-block connector. The JIB/BT8R features balanced Left/Right XLR and 1/4″ line outputs with a volume control. The compact stereo Bluetooth receiver is powered on 5V DC and comes with a removable 2.4GHz antenna. The portable Bluetooth receiver can be placed on a flat surface such as a rack shelf or mounted to a mic stand. DJs accepting requested songs that may not have it in their track can allow a user to Bluetooth® a song straight to their mixing console for live DJ mixing. Singers and musicians can stream audio wirelessly to the receiver. The JIB/BT8R can also be used for a number of other audio streaming applications including dance studios, aerobics, school and gym classes, house of worship, restaurants, nightclubs, event spaces, karaoke, weddings, and many more.
- Transmit Audio from Smart Phone to Active Speaker or Mixer
- Left/Right XLR and 1/4″ Line Out for Stereo Playback
- Lightweight, Compact, Tough, Portable Design
- Volume Control
- Remote Pairing Capability
- Removable 2.4 GHz Antenna
- Stand Mountable (3/8″-5/8″ stand adapter included)
| Bluetooth Version | V4.0 |
|---|---|
| Frequency Range | 2.4GHz - 2.48GHz |
| Output Connector | Left/Right Balanced XLR/M, Left/Right Balanced 1/4" Line |
| Controls | Volume, Wireless Bluetooth® Pair, Remote Pairing Euro-block Connector |
| Indicators | Status LED |
| Sensitivity | -80dBm < +/-0.1% BER |
| Signal to Noise | >75dB |
| Total Harmonic Distortion | <0.1% |
| Operating Range | Under Typical Conditions 32.8' (10 m) Note: actual range depends on RF signal absorption, reflection, and interference. |
| Operating Temperature | Range -40º F to 176º F (-40 Cº to +80 Cº) |
| Mountable | Yes, 5/8" or 3/8" with included adapter |
| Antenna | 2.4 GHz Removable |
| Dimensions | 1.58" x 3.54" x 5.8" (40 x 90 x 147 mm)(HxWxD) |
| Weight | 12.17 oz (345 g) |
| Power Requirements | 5V DC/1A Power Supply (included) |
