Product Description
Galaxy Audio AS-950T* Transmitter For 950 Series
- 16 Selectable UHF Frequencies
- AF L/R Indicator
- Transmits in Stereo or Mono
- Channel LCD Display
- Up/Down Channel Select
- XLR/1/4″ Combo Input
- RF Output 10mW
- Detachable 1/2 Wave BNC Antenna Included
AS-950T TRANSMITTER | |
---|---|
Main Frame Size | EIA STANDARD 1/2 U |
Modulation Mode | FM Stereo Modulation |
RF Output | 10 mW |
Max Audio Input Level | +6dBV |
Gain Adjustment Range | 40dB |
Controls | Headphone Volume, Channel Up/Down, and Power Button |
Indicators | LCD Display, Input Level |
Audio Input | Line Level X 2, XLR / 1/4" Combo Jack |
XLR Input | Impedance balanced Pin 1: Ground (cable shield) Pin 2: Audio + Pin 3: No Audio - |
Transmitter Antenna | Detachable 1/2 Wave BNC Antenna |
Dimensions | 1.73" x 8.34" x 3.77" (44 x 212 x 96 mm) (HxWxD) |
Weight | 19.75 oz (560 g) |
Power Requirements | 12-18 V DC at 300 mA, supplied by external power supply |
