Product Description
Galaxy Audio AS-1410-4* Wireless In-Ear Monitor With EB10 Band Pack
The AS-1400 deepens Galaxy Audio’s acclaimed line of Wireless Personal Monitors, offering high-end features and performance at an affordable price. The transmitter features stereo XLR/1/4 in. inputs, headphone output with volume control, input level control, and LCD display for channel and input level.
The Receiver features Mixed Mono Mode for your own personal mix, volume, and an LCD display with channel, battery level, and RF level. The AS-1400 is perfect for the working musician, House of Worship, or any application requiring an affordable, reliable WPM system.
If you’ve never worked with a wireless personal monitor, you owe it to yourself to try. The Galaxy Audio AS-1400 is an affordable yet professionally featured WPM that may just change the way you perform. Simply plug the AS-1400T into your ‘monitor out’ jacks on the mixing console, create the desired mix, and it’s ready to deliver quality sound. The AS-1400 allows for greater stage freedom and confidence in vocal delivery over floor wedges. The AS-1400 is also effective at eliminating stage noise, protecting users’ ears from damage, allowing the user to move around the stage or audience and continue to hear while eliminating feedback.
The Galaxy Audio Series of Wireless Personal Monitors is a great alternative for performers who are tired of lugging around heavy and bulky floor monitors and tired of leaving a gig with ringing ears.
The AS-1400 is perfect for anyone looking to upgrade to the next level.
The Galaxy Audio AS-1400 Twin Pack and Band Pack IEM Systems make it easy for any duo or band to Get Personal. The AS-1400-2 Twin Pack IEM system includes two receivers and one transmitter. The AS-1400-4 Band Pack system includes four receivers and one transmitter.
An unlimited number of receivers may be added at any time.
See “Configurations” for earbud upgrade system options.
- Featuring Mixed Mono Mode
- 275 Selectable Channels
- UHF Phase Locked Loop
- Blacklit LCD (Displays Channel Number and Freq.)
- Stereo or Mono Transmission
- Single/Dual Rack Mount Kit Included
- Multiple Receivers can be used with 1 Transmitter
- 300′ Range
- EB4 Ear Buds Included
The Mixed Mono feature allows performers to adjust the balance of the Left and Right audio signals sent from the transmitter right on the body pack. With Mixed Mono:
- The performers can have their vocals in Input 1 and the band mix in Input 2 and adjust the volume of each independently to create their own personal mix, or
- You can send two different monitor mixes from the board so each performer can decide which mix they want to hear on their belt pack.
AS-1400T Transmitter
- Transmits in Stereo or Mono
- Light Up LCD Display
- Channel Number and Frequency
- 275 Selectable Channels
- XLR/1/4″ Combo Input
- RF L/R Indicator
- RF Output 30 mW
- Detachable BNC Antenna
AS-1400R Receiver
- LCD Display with Backlight
- Earphone Output Volume Control
- 3 Bar Battery Life Indicator
- RF Indicator
- 100 mW Headphone Output
- EB4 Ear Buds Included
- Operates on 2 AA Batteries (Alkaline or Rechargeable)
- 5.12 oz (145 g)
Band Pack gives you 4 body pack receivers and 4 sets of EB10 Professional Dual Driver earbud upgrades for bands needing to outfit four members to a professional in-ear monitoring system that allows monitoring their mix with full detail. AS-1410-4 Wireless In-Ear Monitor Band Pack System with EB10 earbud upgrade includes
- (1) AS-1400T Transmitter
- (4) AS-1400R Receivers
- (4) EB10 Professional Dual Driver earbuds
- Single/dual rack kit
- Antenna
- Power supply
EB10
GALAXY AUDIO EB10 PROFESSIONAL DUAL DRIVER EARBUDS: Upgrading your earbuds can be a great improvement to your wireless monitor system or media player. The Galaxy Audio EB10 is a professional dual driver earbud system. It has two built-in transducers and a passive crossover in each ear bud. They provide Hi-Dynamics, Hi-Definition, and Low-Noise to yield accurate audio reproduction. The EB10 has a standard 3.5mm stereo jack, allowing it to be used with any brand of Wireless Personal Monitor or Digital Media Player.
The Galaxy Audio EB10 incorporates dual performance drivers and built-in crossover. The EB10's lightweight ergonomic design assures excellent sound isolation and maximum comfort during periods of extended wear. The EB10 comes with a Silver Plated cable with a Gold Plated connector. The EB10 has a MAX Power Input of 150mW and a Sensitivity of 120 dB/mW. The EB10 has a cable over 4 feet long and the ear buds weigh 7g (0.25 oz; excluding cable). The EB10 includes zippered carrying case with a cleaning rod and three pairs of Silicon Sleeves (small, medium and large).
- Professional Dual Driver Earbuds
- Allows musicians to monitor their mix with full detail.
- Design assures excellent sound isolation and maximum comfort during periods of extended wear.
- Three different sized pairs of silicon sleeves are provided for best fit and sound isolation.
- Nylon Soft Case Included
SPECIFICATIONS
| AS-1400 SYSTEM | |
|---|---|
| Band | UHF |
| Frequency Range | CODE M 516 MHz - 558 MHz |
| Frequencies | 275 Selectable Frequencies |
| Transmitter Output Level | 30 mW |
| Operating Range | Under Typical Conditions 300' (92 m) Note: actual range depends on RF signal absorption, reflection, interference, and battery characteristics |
| Audio Frequency Response | +/-3dB 40Hz - 16kHz |
| Total Harmonic Distortion | < 0.4% @ 1kHz |
| Signal to Noise | >105dB |
| Maximum Deviation Range | +/-68kHz |
| Dynamic Range | >90dB A-weighted |
| Operating Temperature | Range 14º F to 122º F (-10º C to 50º C) Note: battery characteristics may limit this range |
| Band Width | 42 MHz |
| AS-1400 TRANSMITTER | |
| Main Frame Size | EIA STANDARD 1/2 U |
| Modulation Mode | FM Stereo Modulation |
| RF Output | 30 mW |
| Max Audio Input Level | +6dBV |
| Gain Adjustment Range | 33dB |
| Audio Input | Line Level X 2, XLR/ 1/4" Combo Jack |
| XLR Input | Balanced Pin 1: Ground (cable shield) Pin 2: Audio + Pin 3: Audio - |
| Audio Output | 1/4" Headphone Out |
| Dimensions | 1.7" x 8.2" x 7.1" (44 x 209 x 180 mm)(HxWxD) |
| Weight | 37.4 oz (1,060 g) |
| Power Requirements | 12-18 V DC at 300 mA supplied by external power supply |
| AS-1400 RECEIVER | |
| Audio Output Level | 100 mW |
| Sensitivity | 6dBμV, S/N>60dB |
| Stereo Separation | 45dB (at 1kHz) |
| Output Connector | 1/8"(3.5 mm) Stereo Earphone Connector |
| Dimensions | 4.33" x 2.56" x 0.87" (110 x 65 x 22 mm)(HxWxD) |
| Weight | 5.12 oz (145 g)(without batteries) |
| Power Requirements | 2 "AA" size alkaline or rechargeable batteries |
| Battery Life | About 7 hours (alkaline) |
